Transparent Led Display Media Player 50 mm x 100 mm High Transparency on Glass Wall
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | VEGOO |
| Certification: | CE ROHS FCC |
| Model Number: | VG-P3.9 / 7.8 mm |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Usd 500 Per Sqm |
| Packaging Details: | 0.202 CBM |
| Delivery Time: | 8-15 working day |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Lifetime Payment Term T/T: 30% Down Payment Before Production, The Balan: | 100,000 Hours | Running Temperature: | –40℃ ～ +60℃ |
|---|---|---|---|
| Weight: | 6.5kgs | Thickness: | 65MM |
| Material: | Aluminium Die Casting | Package: | Flight Case |
| Delivery Time: | 10-25days | Warranty: | 3 Years |
| Usage: | Indoor,Semi-outdoor | Cabinet Size: | 500*1000mm |
| Power Supply: | Great Wall/Meanwell | Pixel Pitch: | 3.91-7.81mm |
| Highlight: | transparent led panel,transparent led video wall |
||
Product Description
About Us:
We are one of the professional led display manufacturers in China and we have our own researching
and developping department for customized led display and solutions .
 |
Shenzhen Vegoo Electronic Technology Co.,Ltd. | |
| ADD: NO.19, Yulv Rd., Guangming new district , Shenzhen, China | ||
| No. | Transparent LED display Specification | |
| 1 | MODULE MODEL | GLS.GTR.039.1921 |
| 2 | INPUT VOLTAGE | DC5V |
| 3 | TRANSPARENCY RATE | 55% |
| 4 | MODULE POWER | 25W |
| 5 | CABINET SIZE(mm) | 500*1000*65mm |
| 6 | MAX COMSUMPTION | 400W/㎡ |
| 7 | Cabinet resolution | W128*H128 |
| 8 | Input voltage | AC220V/(110V)±15%,47～63Hz |
| 9 | Cabinet material | aluminum, PC, stamping parts |
| 10 | cabinet weight | 7.5KG |
| 11 | protection grade | IP42 |
| 12 | pixel pitch | H:3.9mm V:7.8mm |
| 13 | PIXEL DENSITY | 32768 |
| 14 | SCAN MODE | 1/16 |
| 15 | REFRESH RATE | 2880HZ |
| 16 | brightness(CD/m²) | 2500 |
| 17 | Working humidity | 10%～95%RH |
| 18 | working temperature | -20~50C° |
| 19 | working life | ≥30000H |
| 20 | signal transfer | Internet cable |
| 21 | control system | computer synchronous control |
