Lightweight 2.5mm Led Stage Display Screen Indoor 480mm×480mm×90mm
Product Details:
Place of Origin: | China |
Brand Name: | Vegoo |
Certification: | CE/ROHS/FCC/ |
Model Number: | VG-HD 2.5 |
Document: | Product Brochure PDF |
Payment & Shipping Terms:
Minimum Order Quantity: | 1Sq.m |
---|---|
Packaging Details: | Plywood case / Flight case / Carton box |
Delivery Time: | 15 working days |
Payment Terms: | Western Union, T/T |
Supply Ability: | 1500Sqm/months |
Detail Information |
|||
Product Name: | P2.5 Indoor Full Color LED Display | Pixel Pitch: | 2.5mm |
---|---|---|---|
Pixel Configuration: | 1R1G1B/SMD2121 Black Lamp | Density: | 160,000 Pixel/m2 |
Moduel Size(L×W)mm: | 160mm×160mm | Driving Method: | 1/32 Scan |
Driving IC: | MBI5124 | Brightness: | 1000cd/㎡ |
Highlight: | high definition led display,commercial advertising led display |
Product Description
Lightweight P2.5 Indoor Full color LED Display 160,000 pixel/m2
Product Description
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.
P2.5 Indoor Full color LED Display Specification
Product Name | Specification | ||||||||||
Pixel Pitch | 2.5mm | ||||||||||
Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
Density | 160,000 pixel/m2 | ||||||||||
Moduel Size(L×W)mm | 160mm×160mm | ||||||||||
Cabinet Size(L×W×H)mm | 480mm×480mm×90mm | ||||||||||
Module Resolution | 64×64 | ||||||||||
Cabinet Resolution | 192×192 | ||||||||||
Driving Method | 1/32 Scan | ||||||||||
Driving IC | MBI5124 | ||||||||||
Brightness | 1000cd/㎡ | ||||||||||
Contrast | 1000:1 | ||||||||||
Brightness Adjustment | Auto and Manual | ||||||||||
Power Consumption | Max Power:<1200W | ||||||||||
Average power: <480W | |||||||||||
Module Weight | 0.5kg | ||||||||||
Color Temperature | 9500K—11500K | ||||||||||
Horizontal Viewing Angle | 140º | ||||||||||
Vertical Viewing Angle | 140º | ||||||||||
Signal Processing | 10 or 14bit | ||||||||||
Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
Frame Frequency | 65 Hz | ||||||||||
Refresh Rate | >1920Hz | ||||||||||
Control Mode | Synchronous/Asynchronous | ||||||||||
The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
MTBF | >50000 hours | ||||||||||
Life Span | 100,000 Hours | ||||||||||
Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
Storage : -40 - 85 ℃ | |||||||||||
Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
Power Supply | AC 110-220V | ||||||||||
Protection | IP 41 |
Upgrade Service :
Unschedule,we will upgrade our system of products without extra formal; we’ll do our best to help users with upgrading ; the following conditions are excluded by this warranty :
1. Without approved documents;
2. Series code on products having been torn or changed ;
3. Damage caused by lighting strike or electrical problems;
4. Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.
5. Users or third party refit or repaired by themselves without VEGOO’s permission ;
6. Water intrusion or corrosion caused by improper keeping or operating ;
7. Over period of free maintenance .
