Outdoor Waterproof P8 Fixed Advertising Video Screen SMD LED Display Billboard Out of Home Advertising DOOH Pantalla
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE,FCC,RoHS |
| Model Number: | VG-P8-B |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 6000 Sqm/month |
|
Detail Information |
|||
| Color: | Full Color | Panel Size: | 960x960mm |
|---|---|---|---|
| Pixel Pitch: | 8mm | Pixel Density: | 15,625dots/Sqm |
| Highlight: | DOOH Pantalla LED Display Billboard,Outdoor Waterproof LED Display Billboard,P8 Fixed Advertising Video Screen |
||
Product Description
Outdoor Waterproof P8 Fixed Advertising Video Screen SMD LED Display Billboard Out of Home Advertising DOOH Pantalla
1. LED Electronic Display System is a multimedia hi-tech product that blended optical, electronic and acoustic signal processing technologies. It includes the followings devices:
Display screen
Control computer and communication system
Computer and its related peripheral
Video peripheral
System software
2. System Features:
Available for connection to an external scanner, and accepting various pictures, graphs and handwriting inputs.
Accepting video signal (TV, VCR, DVD), and showing dynamic images as well as graphs and animations.
The control computer can act as a workstation on network, and read real-time data from specified computer, then show them on its display.
Various methods for images display, and easy replacement for arranged programs whenever (including play sequence, time length, etc.)
| Specification and main technical index | ||||
| (1)Construction Description | ||||
| 1,Screen consists of cabinets ,cabinet consist of modules 2,modules consist of pixels and each pixel contains 1R1PG1PB total of 1 LED lamps |
||||
| (2)Professional analysis | ||||
| No. | Professional analysis content | Analysis item | ||
| (3)Pixel Parameter | ||||
| No. | Item | Parameter | ||
| 1 | Pixel pitch | PH8mm | ||
| 2 | Pixel configuration | 1R 1PG 1PB | ||
| (4)Tube Chip Parameter | ||||
| No. | Item | Wavelength | Brightness | |
| 1 | Red tube chip | 620-625nm | 800-1000mcd | |
| 2 | Pure green tube chip | 520-525nm | 2200-3000mcd | |
| 3 | Pure blue tube chip | 465-470nm | 300-600mcd | |
| (5) Electricity parameter | ||||
| 1 | Pixel density(dots/M2) | 15,625dots/ m² | ||
| 2 | White Balance Brightness | ≥6500 (cd/m²) | ||
| 3 | Brightness Adjusted | 256 grade automatically, 8 grade manually | ||
| 4 | Color temperature(K) | 5000-9500 | ||
| 5 | View Angle | Horizontal:140°; Vertical: 110° | ||
| 6 | Best viewing distance(m) | 6-50m | ||
| 7 | Communication distance | 120 meters by LAN cable(without relay) | ||
| 8 | Drive Method | 1/4 scan constant current | ||
| 9 | Gray Grades | 16384 levels for each color | ||
| 10 | Display Color | 16,777,216 | ||
| 11 | Refresh Frequency (Hz) | 960 | ||
| 12 | Control Mode | Synchronous controller/Asynchronous controller | ||
| 13 | Signal interface | DVI | ||
| 14 | Input signal | Video: PAL/NTSC etc | ||
| 15 | Display format | 800 * 600,1024 * 768, 1280*1024 | ||
| 16 | Software | Support windows series system | ||
| 17 | Waterproof | Yes | ||
| 18 | Protection | IP65 | ||
| 19 | Working temperature(ºC) | (-20ºC~+60ºC ) | ||
| 20 | Humidity(RH) | 10%-90%RH | ||
| 21 | LED Lifetime(hours) | ≥100,000 | ||
| 22 | Whole Display Flatness | Less than 1mm Juncture | ||
| 23 | Power Consumption | Average:≤250w/m²;Maximum: ≤1000w/m² | ||
| 24 | Operating Voltage | AC100V±220V 50~60HZ | ||
| 25 | Operating Platform | WINDOWS(WIN10,WIN8, WIN XP) | ||
