P3 Indoor LED Display Ultra Slim HD Video Wall for Conference Information Board
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE,FCC,RoHS |
| Model Number: | VG-P3-VideoWall |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 8000 Sqm/month |
|
Detail Information |
|||
| Pixel Pitch: | 3mm | Density: | 111,111pixel/m2 |
|---|---|---|---|
| Moduel Size(L×W)mm: | 192mm×192mm | Module Resolution: | 64×64 |
| Material: | Aluminum Die-casting | Property: | Lightweight, Portable |
| Highlight: | P3 Indoor LED Display,Ultra Slim Indoor LED Display,Conference Information Board Indoor LED Display |
||
Product Description
High Definition P3 Led Screen Indoor Tv LED screen 192*192mm module
| P3 Indoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 3mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
| 3 | Density | 111,111pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 192mm×192mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 576mm×576mm or 768×768mm×100mm | ||||||||||
| 6 | Module Resolution | 64×64 | ||||||||||
| 7 | Cabinet Resolution | 192×192 or 256×256 | ||||||||||
| 8 | Driving Method | 1/32 Scan | ||||||||||
| 9 | Driving IC | FM6124 | ||||||||||
| 10 | Brightness | 800cd/㎡ | ||||||||||
| 11 | Contrast | 1000:1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜545W | ||||||||||
| 14 | Average power: ＜165W | |||||||||||
| 15 | Cabinet Weight | 20kg/25kg | ||||||||||
| 16 | Color Temperature | 2000K—9500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 16bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >1920Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 110-220V/5V60Hz | ||||||||||
| 36 | Protection Level | IP 45 | ||||||||||
FAQ
1,What about the lead time?
A:Within 15 working days after receiving the deposit.
2,Can you provide customized services?
A:Yes,We can design different category of products according to your demand.
3, Is it OK to print our logo on led screen product?
A:Yes,we can print your logo according your request.
4,Can I order a sample for led display screen?
A:Yes, we warmly welcome you to order a sample to test and check quality. You can choose any item what you want.
5,Is it OK to print our logo on led screen product?
A:Yes,we can print your logo according your request.
