Outdoor HD Stage Indoor 3mm P2.5 Full Color LED Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE |
| Model Number: | VG-P2.5-DH2 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 Sqm/month |
|
Detail Information |
|||
| Pixel Pitch: | 2.5mm | Module Size: | 160*160mm |
|---|---|---|---|
| LED Lamp: | SMD2121 | Cabinet Size: | 480*480mm |
| Highlight: | P2.5 led display tv screens,3mm full hd led panel |
||
Product Description
Full Color Led Panels Display Outdoor Hd Stage Indoor 3mm Led Video Wall P 2.5 Full Color Led Display
| Module Parameters | |||||
| Pixel Pitch | 2.5mm | ||||
| Pixel Configuration | 1R1G1B | ||||
| Density | 160000 pixels/sqm | ||||
| LED Lamp | SMD2121 | ||||
| Module Size | 160*160mm | ||||
| Module Resolution | (W)64Pixels * (H)64Pixels | ||||
| Working Voltage | DC5V | ||||
| Scan Mode | 1/32 Scan | ||||
| Drive IC | MBI5124(Can be customized) | ||||
| Port Type | HUB75 | ||||
| Screen Parameters | |||||
| Cabinet Size | (W)480*(H)480mm | ||||
| Cabinet Material | Die-casting aluminum | ||||
| Cabinet Weight | 5.76KG | ||||
| Cabinet Resolution | 192*192 Pixels | ||||
| Module Qty | 9pcs | ||||
| Power Supply | 200W | ||||
| Working Voltage | AC220V±10% | ||||
| Max Power Consumption | 600W/sqm | ||||
| Ave Power Consumption | 200W/sqm | ||||
| Brightness | 800 Nits | ||||
| Refresh Rate | 1920Hz/ 3840Hz | ||||
| Frame Frequency | 60Hz | ||||
| Grey Scale | 14 bit | ||||
| Brightness Level | 256 levels | ||||
| Best View Distance | 2.5M-50M | ||||
| View Angle | 120°(Horizontal); 120°(Vertical) | ||||
| Protection Degree | IP30 | ||||
| Working Temperature | -20℃ ~ +60℃ | ||||
| Relative Humidity | 10%-95% | ||||
| Operation system | WIN7/WIN8 | ||||
| Control Method | Synchronous or Asynchronous | ||||
| Control System | NovaStar | ||||
| Receiving Card | MRV336 | ||||
| Control Distance | 100M(Ethernet cable); 20KM(Optical fiber cable) | ||||
| Input Signal | Composite Video, S-video, DVI, HDMI, SDI, HD-SDI | ||||
| Out-of-Control Pixel Rate | ≤0.01% | ||||
