Removable RGB SMD 6mm Rental LED Display For Stages
Product Details:
Place of Origin: | China |
Brand Name: | Vegoo |
Certification: | CE/ROHS/FCC/CCC |
Model Number: | VG-SUN88823 |
Document: | Product Brochure PDF |
Payment & Shipping Terms:
Minimum Order Quantity: | Negotiation |
---|---|
Price: | Negotiable |
Packaging Details: | Flight case,plywood box,carton |
Delivery Time: | 10-25 days |
Payment Terms: | L/C, T/T |
Supply Ability: | 3000sq.m/month |
Detail Information |
|||
Product Name: | Rental LED Display | Pixel Pitch: | 6mm |
---|---|---|---|
Module Size(L×W)mm: | 192×192 | Material: | Aluminum Or Iron |
Feature: | High Resolution | Brightness: | 6500cd/㎡ |
Highlight: | 6mm rental led display screen,SMD led backdrop screen rental |
Product Description
Easy Installation Removable Rental RGB LED Display SMD Full Color Panel For Stages
Our core advantage:
1. Compatible with multiple functions:VGA, Video, AVI, MOV, MPG, DAT, VOB and so on.
2. Clear picture show without flicker and distortion.
3. Brightness, contrast and saturation can be adjusted automatically or manual.
4. Display content with your PC synchronously.
5. Customized for indoor or outdoor use,the pixel pitch is optional.
Rental LED Display Specification
Product Name | Rental LED Display | ||||||||||
Pixel Pitch | 6mm | ||||||||||
Pixel Configuration | 1R1G1B/SMD3535 | ||||||||||
Density | 27,777 pixel/m2 | ||||||||||
Moduel Size(L×W)mm | 192mm×192mm | ||||||||||
Cabinet Size(L×W×H)mm | 576mm×576mm×90mm | ||||||||||
Module Resolution | 32×32 | ||||||||||
Cabinet Resolution | 96×96 | ||||||||||
Driving Method | 1/8 Scan | ||||||||||
Driving IC | MBI5124 | ||||||||||
Brightness | 6500cd/㎡ | ||||||||||
Contrast | 1000:1 | ||||||||||
Brightness Adjustment | Auto and Manual | ||||||||||
Power Consumption | Max Power:<545W | ||||||||||
Average power: <165W | |||||||||||
Module Weight | 0.244kg | ||||||||||
Color Temperature | 9500K—11500K | ||||||||||
Horizontal Viewing Angle | 140º | ||||||||||
Vertical Viewing Angle | 140º | ||||||||||
Signal Processing | 10 or 14bit | ||||||||||
Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
Frame Frequency | 65 Hz | ||||||||||
Refresh Rate | >1920Hz | ||||||||||
Control Mode | Synchronous/Asynchronous | ||||||||||
The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
MTBF | >50000 hours | ||||||||||
Life Span | 100,000 Hours | ||||||||||
Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
Storage : -40 - 85 ℃ | |||||||||||
Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
Power Supply | AC 110-220V |
Customer Service
1) Guarantee Time: Within one year after delivery form factory
2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )
3) Maintenance Mode :
By returned maintenance , through express or by other way
4) Response time for maintenance :
Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;
Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;
On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.
