High Precision and Seamless Splicing Curved Rental LED Display for Exhibition IP43 Grade
Product Details:
Place of Origin: | China |
Brand Name: | Vegoo |
Certification: | CE/ROHS/FCC/CCC |
Model Number: | VG-RENTAL-P2.604 |
Document: | Product Brochure PDF |
Payment & Shipping Terms:
Minimum Order Quantity: | 1㎡ |
---|---|
Price: | Negotiation |
Packaging Details: | Flight case/Wooden case |
Delivery Time: | 7-15 days |
Payment Terms: | T/T in advance(50% deposit) |
Supply Ability: | negotiation |
Detail Information |
|||
Ip Grade: | IP43 | Grey Level: | 12-14 Bit |
---|---|---|---|
Moduel Size: | 250*250 | Cabinet Material: | Die-casting Aluminum |
Highlight: | Exhibition Curved Rental LED Display,Seamless Splicing Curved Rental LED Display,High Precision Curved Rental LED Display |
Product Description
Curved rental P3.91 indoor exhibition art show product can widely use in many fields, which can attract visitors' or clients' attention.
Feathers
1.Die-castingaluminum,lowtemp-rise
2.Highrefresh,lowlighthighgray
3.Highprecision,seamlesssplicing
4.Nofan,mutedesign,noise-free
5.Lowpower,Eco-friendly
Product Parameters
CABINET SOLUTION | |||||||||||||
Demension | Width | 500mm | Height | 500mm | |||||||||
Resolution | 128 | pixel | 128 | pixel | 16,437 | dots | |||||||
Thickness | 65mm | ||||||||||||
Weight | 6.5kg | ||||||||||||
Material | Aluminum Die-casting |
SCREEN | |||||||||||||
Item | Description | ||||||||||||
Model | P3.91 | ||||||||||||
Screen | Cabinet Compostion | 26 | pcs | (W) | X | 10 | pcs | (H)= | 260 | pcs | |||
display size | 13.000 | m | (W) | X | 5.000 | m | (H)= | 65.00 | m² | ||||
Resolution | 3324.808184 | pixels | (W) | X | 1279 | pixels | (H)= | 4,251,673 | pixels | ||||
Maximum power consumption(W/M²) | 700 | ||||||||||||
Average power consumption(W/M²) | 260 | ||||||||||||
Drive IC | ICN1065S | ||||||||||||
Power supply | 5V40A | ||||||||||||
Brightness | >800-1000 CD per sqaure meter. | ||||||||||||
Colors | 68.7 billions. | ||||||||||||
Best Viewing Distance | 10-60 m | ||||||||||||
Gray Scale | 12-14Bit | ||||||||||||
Input Power | AC220V/50Hz or AC110V/60Hz | ||||||||||||
Driving Mode | Constant current 1/16 scan | ||||||||||||
Refresh Rate | ≥3840-7680Hz | ||||||||||||
Control distance | CAT5 cable<100m, Single fiber<10km | ||||||||||||
Control Mode | Synchronization control | ||||||||||||
Lifetime (50% Brightness) | 100,000 Hours | ||||||||||||
Running Temperature | –40℃ ~ +60℃ | ||||||||||||
Humidity | 10% ~70% | ||||||||||||
Singal Available | DVI,S-VIDEO, RGB, VGA and ETC. | ||||||||||||
Running Files | Text, Animation, Picture, Video and etc | ||||||||||||
Controlling Systerm | Nova | ||||||||||||
Operating Systerm | Windows 7 | ||||||||||||
Ingress Protection | IP 43 |
Other parameter
Dimensions per Unit | 0.6 x 0.6 x 0.12 Meters |
---|
Export Carton Dimensions L/W/H | 1.0 x 0.8 x 0.8 Meters |
---|
