Seamless Assembly Pixel Pitch P4.81 Rental LED Display with High-Precision Die-Cast Aluminum Cabinets
Product Details:
Place of Origin: | China |
Brand Name: | VEGOO |
Certification: | CE ROHC FCC |
Model Number: | VG-P4.81-500mm*500mm |
Document: | Product Brochure PDF |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Cabinet |
---|---|
Price: | Negotiable |
Packaging Details: | Wooden box or Flight case |
Delivery Time: | 15-25days |
Payment Terms: | T/T |
Supply Ability: | 8000sqm per month |
Detail Information |
|||
Display Function: | Video/image | Warranty: | 2 Years |
---|---|---|---|
Waterproof Grade: | IP65 | Led Refrsh Rate: | 3840hz |
Scanning Mode: | 1/13 | Maintenance Connection Mode: | Maintenace From The Back |
Operating Temperature: | -20°C~+50°C | Software: | Nova |
Gray Scale: | 16 Bit | ||
Highlight: | Pixel Pitch P4.81 Rental LED Display,Seamless Assembly Rental LED Display |
Product Description
Key Specifications/ Special Features:
1.Back-and-front service Environmental-friendly structures for maintenance that is designed for all-purpuse installation sites.
2.Modular design-hard connceting interface Modules,power and system parts are connected through hard connecting interface,convenient to connect and use.
3.Seamless assembly High-precision die-cast aluminum cabinets with space between them not large than 0.1mm.
4.Various ways of cabinet combination One of the highlights of R-series include protability, rich transformation.Cabinets can be suspended in parallel,arragned horizonally in a curved angle,and mounted in stories.
The advangtages of rental screens:
1.Wide viewing angle, high contrast, seamless splicing, and high image quality. LED rental screens should have the functions of "beautiful appearance, lightweight,easy to carry, and stable quality", as well as wide viewing angle, high contrast, smooth patches, and high definition.Especially for LED rental screen casings used in the stage and enterainment industry, they are mostly made of aluminum boxes,with a weight of around 20-30kilograms/m2.They are lightweight,ultra-thin,and easier to disassemble.
2.Long lifespan The main component that affects the lifespan of LED rental screen is light-emitting diodes(LEDs).High temperature is the natural enemy of LEDs,and aluminum boxes have good thermal conductivity, which can stabilize environmental temperature and greatly extend the lifespan of display screens.
3.Good stability The stengthening of the stability of LED rental screens is also one of the important factors widely accepted by most businesses.LED rental screens are often used for large-scale events such as advertising, performancess,gatherings,and press releases,and their stability plays an important role throughtout the entire process. Therefore,when selecting materials, enterprises will conduct relevant tests with requirements higher than industry
Technical Parameter
Unit Module | Item | Parameter | |
Model Number | VG-P4.81- 13S | ||
Module Size | 250mm*250mm | ||
Physical Pitch | 4.81mm | ||
Physical Density | 43264 Dots/m2 | ||
Pixel Configuration | 1R1G1B | ||
Package Mode | SMD 3IN1 -2727 | ||
Pixel Resolution | 52dots(W)*52dots(H) | ||
Max Power | 25W | ||
Module Thickness | 16mm | ||
Weight | 560g | ||
Drive Type | Constant drive | ||
Scan Mode | 1/ 13 扫描 1/ 13scan | ||
Port Type | HUB75 | ||
Match Cabinet | W500mm*H500mm W500mm*H1000mm |
Display Parameters | Dimension | 500mm*500mm |
Thickness | 90mm | |
Weight | 8kg | |
Monomer Module Number | 4pcs | |
Maintenance Connection Mode | Maintenance from the Back | |
Pixel per Cabinet | 10816 pixels | |
Best Viewing Angle | H:140°;V:120° | |
Recommended Viewing | 4.8m-30m | |
Driver IC | ICND2038S/2153/5124 | |
Refresh Rate | 3840Hz | |
Brightness of White Balance | 6000cd/㎡ | |
Operating Temperature/Humidity | -20℃ ~ +50℃ | |
Life Time | > 100000 hours | |
Bad Light Rate | <0.0001 | |
MTBF | >5000 hours | |
Cabinet Matching Module Size | 250mmx250mm | |
Cabinet Matching Module Model | P2.6/P2.97/P3.91/P4.81 | |
Power | Input Voltage | 110-220V;AC±10% |
Power Supply | 5V/60A*1pcs | |
Working Voltage | 110V-220V AC±10% | |
Average Power Consumption | 260w/㎡ | |
Max. Power Consumption | 800w/㎡ | |
Control system | CPU | Pentium4 or Above |
Operation System | WIN98/2000/NT/XP/WIN7 | |
Control Method | Synchronization |
Detail Images
