Remote Control Full Color P5 HD SMD LED Module Display Electronic Advertising Video Screens
Product Details:
| Place of Origin: | China |
| Brand Name: | Vgeoo |
| Certification: | Ce/ROHS/FCC/CCC |
| Model Number: | VG-SUN88819 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | negotiate |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 7~25 days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Product Name: | Full Color LED Module | Pixel Pitch: | 5mm |
|---|---|---|---|
| Driving Method: | 1/16 Scan | Brightness: | 4500cd/㎡ |
| Density: | 65,536 Pixel/m2 | Driving IC: | MBI5124 Or ICN 2038S |
| Contrast: | 1000:1 | Warranty: | 3years |
| Highlight: | led screen module,led video module |
||
Product Description
Remote Control Full Color P5 HD LED SMD Module Display Electronic Advertising Video Screens
Our Advantage:
1.Remote Control:Will send alarm email to operators once accured LED lamp failure or other issue to make the lamp failure. (Be customized)
2.Protection:Waterproof IP65, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)
3.Customize:Pixel pitch is optional,it depends on your needs.The size of the modlue or cabinet also is optional.It can be choose for outdoor or indoor use.
P5 Outdoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 5mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD2727 | ||||||||||
| Density | 40,000 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 320mm×160mm | ||||||||||
| Cabinet Size(L×W×H)mm | 640mm×640mm×130mm | ||||||||||
| Module Resolution | 64×32 | ||||||||||
| Cabinet Resolution | 192×192 | ||||||||||
| Driving Method | 1/8 Scan | ||||||||||
| Driving IC | FM6124 | ||||||||||
| Brightness | 6000cd/㎡ | ||||||||||
| Contrast | 6000 :1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜650W | ||||||||||
| Average power: ＜325W | |||||||||||
| Cabinet Weight | 12kg | ||||||||||
| Color Temperature | 2000K—9500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 16bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >1920Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110-220V/5V60Hz | ||||||||||
| Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
Our service
1. We will reply you within 24hours and resolve your problem as soon as possible.
2. OEM order accepted.
3. 3 years warranty
4.Free technician training and free repair during warranty after sales.
5.Top quality+Reasonable price+Responsible After Service=Successful & Win
