Commercial Advertising P16 Outdoor Full Color Led Display 3906 Pixel/M2

China Commercial Advertising P16 Outdoor Full Color Led Display 3906 Pixel/M2 supplier

Large Image :  Commercial Advertising P16 Outdoor Full Color Led Display 3906 Pixel/M2

Product Details:

Place of Origin: China
Brand Name: Vgeoo
Certification: Ce/ROHS/FCC/
Model Number: VG-RD P16

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sq.m
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 7 days
Detailed Product Description
Product Name: P16 Outdoor Full Color LED Display Pixel Configuration: 1R1G1B/DIP 546
Moduel Size(L×W)mm: 256mm×256mm Module Resolution: 16×16
Driving IC: MBI5124 Brightness: 8500cd/㎡
High Light:

led screen module


led video module


commercial advertising P16 Outdoor Full color LED Display





Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instructio


Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.::



P16 Outdoor Full color LED Display Specification


NO: Product Name Specification
1 Pixel Pitch 16mm
2 Pixel Configuration 1R1G1B/DIP 546
3 Density 3,906 pixel/m2
4 Moduel Size(L×W)mm 256mm×256mm
5 Cabinet Size(L×W×H)mm 1024mm×1024mm×130mm
6 Module Resolution 16×16
7 Cabinet Resolution 64×64
8 Driving Method Static
9 Driving IC MBI5124
10 Brightness 8500cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power: <1200W
14 Average power: <550W
15 Module Weight 0.8kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)




Products exchanged or returned :


we supply our products strictly according to the contract list , if the quantity or specification doesn't meet our contract list, the buyer can give objections within 3 days after received the products , we’ll exchanged after company confirmed.


Casual damage situation:


We can provide corresponding fittings without extra fee when improper operation or unexpected artificial damaged arise .


Over Guarantee time :


You only have to pay maintenance cost such as labor costs , spare parts costs and round-trip costs !
