High Brightness HD LED Display Wall For For Indoor Advertising Municipal Engineering
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/ |
| Model Number: | VG-HD 2.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Sq.m |
|---|---|
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 15 working days |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 1500Sqm/months |
|
Detail Information |
|||
| Product Name: | HD LED Display | Application: | Indoor Advertising Municipal Engineering |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B/SMD1515 Black Lamp | Moduel Size(L×W)mm: | 128mm×128mm |
| Module Resolution: | 64×64 | Driving Method: | 1/32 Scan |
| Driving IC: | MBI5153 | Brightness: | High Brightness |
| High Light: | high definition led display,high resolution led display |
||
Product Description
High Brightness HD LED Display Wall For For Indoor Advertising Municipal Engineering
HD LED Display Application
Indoor advertising, municipal engineering, theme park, gymnasium, large exhibition hall, etc
HD LED Display Feature
With the best LED industrial waterproof and ultraviolet-proof SMD 3 in 1 technology to get a super wide viewing angle and abetter surface flatness and stability. when the screen is used
RGB deep gray processing to show colorful and exquiste images
Supporting point-to-point correction function, ensure the consistency of the color and the brightness in the process of using
Good Heat Dissipation, Easy Installation:
Inner fixed reinforcement plate, tensile and shockproof, auto heat dissipation, make the life span last over ten years
Accurate, Quick, flexible installation, can effectively apply to different situarion
High IP Level Safety and Stability:
With the professional aviation plug as the connectors to ensure the quality
With the high quality raw material, mature craft and large scale production, the quality guaranted
HD LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 2.0mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD1515 Black lamp | ||||||||||
| Density | 250,000 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 128mm×128mm | ||||||||||
| Cabinet Size(L×W×H)mm | 512mm×512mm×90mm | ||||||||||
| Module Resolution | 64×64 | ||||||||||
| Cabinet Resolution | 256×256 | ||||||||||
| Driving Method | 1/32 Scan | ||||||||||
| Driving IC | MBI5153 | ||||||||||
| Brightness | 600CD/㎡ | ||||||||||
| Contrast | 1000:1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜1000W | ||||||||||
| Average power: ＜500W | |||||||||||
| Module Weight | 0.21kg | ||||||||||
| Color Temperature | 6000K—9000K | ||||||||||
| Horizontal Viewing Angle | 120º | ||||||||||
| Vertical Viewing Angle | 120º | ||||||||||
| Signal Processing | 10 or 14bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >3840Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110-220V | ||||||||||
| Protection | IP 41 | ||||||||||
Customer Service
1) Guarantee Time: Within one year after delivery form factory
2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )
3) Maintenance Mode :
By returned maintenance , through express or by other way
4) Response time for maintenance :
1. Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;
2. Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;
3. On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.
