Narrow Bezel Full HD LED Display Screen Entire Die Casting Aluminum High Gray Level

China Narrow Bezel Full HD LED Display Screen Entire Die Casting Aluminum High Gray Level supplier

Large Image :  Narrow Bezel Full HD LED Display Screen Entire Die Casting Aluminum High Gray Level

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-HD 1.667

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 15 working days
Payment Terms: Western Union, T/T
Supply Ability: 1500Sqm/months
Contact Now
Detailed Product Description
Product Name: HD LED Display Pixel Pitch: 1.667mm
Pixel Configuration: 1R1G1B/SMD1010 Black Lamp Moduel Size(L×W)mm: 200mm×150mm×8mm
Module Resolution: 120×90 Feature: Narrow Bezel

Narrow Bezel Full HD LED Display Screen Entire Die Casting Aluminum High Gray Level



HD LED Display advantage



1. High contrast

LED professional lamp bead USES high quality 2121 black lamp, raise luminescence brightness, reduce screen black time brightness at the same time.

Unique black mask processing technology, the screen contrast is greatly improved.



2. High gray level

The display of the screen is almost perfect with low brightness, and the appearance of the screen is higher than the traditional display.

That can show more image details, no information loss.



3. High refresh rate

The screen intake five black screen picture stability without ripples, dealing with the dynamic display screen, the image edge is clear, the screen has good dynamic performance, the image information accurately real reduction, make the video screen clear fluid, bring good visual enjoyment.



4. Wall installation to streamline space

Pasted wall, Mosaic, landing multiple installation methods, simple and beautiful, the maintenance of post-maintenance is more simple and convenient.



HD LED Display Applications:



HD LED Display is widely used in Wedding Ceremony, TV Stations, Contest - TV Station, Contest, - School, TV Shows, Exhibitions, Indoor and outdoor architectures, Commercial Marketing Performances, Public Square etc.They can replace any posters and static billboards and display any animation, video, or text with sound, and supply different experience and effect for clients’ advertisements.



HD LED Display Specification



NO: Product Name Specification
1 Pixel Pitch 1.667mm
2 Pixel Configuration 1R1G1B/SMD1010 Black lamp
3 Density 360,000 pixel/m2
4 Moduel Size(L×W)mm 200mm×150mm×8mm
5 Cabinet Size(L×W×H)mm 400mm×300mm×65mm
6 Module Resolution 120×90
7 Cabinet Resolution 240×180
8 Driving Method 1/30 Scan
9 Driving IC MBI5153
10 Brightness 600cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:<950W
14 Average power: <350W
15 Module Weight 0.45kg
16 Color Temperature 2000K—12000K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >3840Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 85-264V
36 Protection Level IP41



Our service



1. Your inquiry related to our products or price will be replied in 2hrs

2. OEM customized products

3. 2 years warranty

4. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

5.Free technician training..

6.Top quality+Reasonable price+Responsible After Service=Successful & Win



Products exchanged or returned :

we supply our products strictly according to the contract list , if the quantity or specification doesn't meet our contract list, the buyer can give objections within 3 days after received the products , we’ll exchanged after company confirmed.
