High Brightnes Waterproof Dustproof Outdoor Led Module P10 Full Color Led Display

China High Brightnes Waterproof Dustproof Outdoor Led Module P10 Full Color Led Display supplier
High Brightnes Waterproof Dustproof Outdoor Led Module P10 Full Color Led Display supplier High Brightnes Waterproof Dustproof Outdoor Led Module P10 Full Color Led Display supplier

Large Image :  High Brightnes Waterproof Dustproof Outdoor Led Module P10 Full Color Led Display

Product Details:

Place of Origin: China
Brand Name: Vgeoo
Certification: Ce/ROHS/FCC/
Model Number: VG-RD P10

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sq.m
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 7 days
Contact Now
Detailed Product Description
Product Name: P10 Outdoor Full Color LED Display Pixel Pitch: 10mm
Density: 10,000 Pixel/m2 Moduel Size(L×W)mm: 320mm×160mm
Cabinet Size(L×W×H)mm: 960mm×960mm×130mm Module Resolution: 32×16
Cabinet Resolution: 96×96 Driving IC: MBI5124 Or ICN 2038S
Brightness: 7500CD /㎡ Contrast: 1000:1



waterproof, dustproof P10 Outdoor Full color LED Display





Description:



1. Low power consumption;

2. High brightness;

3. Any form what customers required;

4. Low price and timely delivery time;

5. Professional team guide hand by hand and technical supporting;

6. Riched and matured experience on manufacture LED display;

7. Owed many controller suppliers.





Protection

waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)





P10 Outdoor Full color LED Display Specification



Product Name Specification
Pixel Pitch 10mm
Pixel Configuration 1R1G1B/SMD3535
Density 10,000 pixel/m2
Moduel Size(L×W)mm 320mm×160mm
Cabinet Size(L×W×H)mm 960mm×960mm×130mm
Module Resolution 32×16
Cabinet Resolution 96×96
Driving Method 1/ 2 Scan
Driving IC MBI5124 or ICN 2038S
Brightness 7500CD /㎡
Contrast 1000:1
Brightness Adjustment Auto and Manual
Power Consumption Max Power: <700W
Average power: <300W
Module Weight 0.28kg
Color Temperature 9500K—11500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 10 or 14bit
Grey Processing 1024×1024×1024
16834×16834×16834
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >1920Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 85-264V
Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)







Upgrade Service :





Unschedule,we will upgrade our system of products without extra formal; we’ll do our best to help users with upgrading ; the following conditions are excluded by this warranty :

1. Without approved documents;

2. Series code on products having been torn or changed ;

3. Damage caused by lighting strike or electrical problems;

4. Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.

5. Users or third party refit or repaired by themselves without VEGOO’s permission ;

6. Water intrusion or corrosion caused by improper keeping or operating ;

7. Over period of free maintenance .
