• P2 Advertising HD LED Display Indoor Full Color LED Screen For Large Exhibition Hall
  • P2 Advertising HD LED Display Indoor Full Color LED Screen For Large Exhibition Hall
P2 Advertising HD LED Display Indoor Full Color LED Screen For Large Exhibition Hall

P2 Advertising HD LED Display Indoor Full Color LED Screen For Large Exhibition Hall

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-HD 2.0

Payment & Shipping Terms:

Minimum Order Quantity: 1Sq.m
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 15 working days
Payment Terms: Western Union, T/T
Supply Ability: 1500Sqm/months
Get Best Price Contact Now

Detail Information

Product Name: P2.0 Indoor Full Color LED Display Pixel Pitch: 2.0mm
Pixel Configuration: 1R1G1B/SMD1515 Black Lamp Moduel Size(L×W)mm: 128mm×128mm
Module Resolution: 64×64 Driving Method: 1/32 Scan
Driving IC: MBI5153 Brightness: 600cd/㎡
High Light:

high definition led display

,

high resolution led display

Product Description



advertising P2.0 Indoor Full color LED Display for large exhibition hall



Basic introduction



Application for Indoor advertising, municipal engineering, theme park, gymnasium, large exhibition hall, etc
Super Wide Viewing Angle With Exquiste Image
With the best LED industrial waterproof and ultraviolet-proof SMD 3 in 1 technology to get a super wide viewing angle and abetter surface flatness and stability. when the screen is used
RGB deep gray processing to show colorful and exquiste images
Supporting point-to-point correction function, ensure the consistency of the color and the brightness in the process of using
Good Heat Dissipation, Easy Installation:
Inner fixed reinforcement plate, tensile and shockproof, auto heat dissipation, make the life span last over ten years
Accurate, Quick, flexible installation, can effectively apply to different situarion
High IP Level Safety and Stability:
With the professional aviation plug as the connectors to ensure the quality

With the high quality raw material, mature craft and large scale production, the quality guaranted





P2.0 Indoor Full color LED Display Specification



Product Name Specification
Pixel Pitch 2.0mm
Pixel Configuration 1R1G1B/SMD1515 Black lamp
Density 250,000 pixel/m2
Moduel Size(L×W)mm 128mm×128mm
Cabinet Size(L×W×H)mm 512mm×512mm×90mm
Module Resolution 64×64
Cabinet Resolution 256×256
Driving Method 1/32 Scan
Driving IC MBI5153
Brightness 600CD/㎡
Contrast 1000:1
Brightness Adjustment Auto and Manual
Power Consumption Max Power:<1000W
Average power: <500W
Module Weight 0.21kg
Color Temperature 6000K—9000K
Horizontal Viewing Angle 120º
Vertical Viewing Angle 120º
Signal Processing 10 or 14bit
Grey Processing 1024×1024×1024
16834×16834×16834
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >3840Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 110-220V
Protection IP 41





P2 Advertising HD LED Display Indoor Full Color LED Screen For Large Exhibition Hall 0





Customer Service





1) Guarantee Time: Within one year after delivery form factory

2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )

3) Maintenance Mode :

By returned maintenance , through express or by other way

4) Response time for maintenance :



1. Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;



2. Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;



3. On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.
