Remote Control P1.667 HD LED Display Led Stadium Advertising Boards 200mm×150mm×8mm
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/ |
| Model Number: | VG-HD 1.667 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Sq.m |
|---|---|
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 15 working days |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 1500Sqm/months |
|
Detail Information |
|||
| Product Name: | P1.667 Indoor Full Color LED Display | Pixel Pitch: | 1.667mm |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B/SMD1010 Black Lamp | Moduel Size(L×W)mm: | 200mm×150mm×8mm |
| Module Resolution: | 120×90 | Brightness: | 600cd/㎡ |
| High Light: | high definition led display,commercial advertising led display |
||
Product Description
Description:
1 . High quality :Use high quality LEDs with high luminous efficiency and low brightness decay to make the display stable.
2 . Good effect:To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.
3 . Good uniformity:Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well.
Applications:
For Events, Wedding Ceremony, TV Stations, Contest - TV Station, Contest, - School, TV Shows, Exhibitions, Indoor and outdoor architectures, Commercial Marketing Performances, Public Square etc.They can replace any posters and static billboards and display any animation, video, or text with sound, and supply different experience and effect for clients’ advertisements.
P1.667 Indoor Full color LED Display Specification
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 1.667mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD1010 Black lamp | ||||||||||
| 3 | Density | 360,000 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 200mm×150mm×8mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 400mm×300mm×65mm | ||||||||||
| 6 | Module Resolution | 120×90 | ||||||||||
| 7 | Cabinet Resolution | 240×180 | ||||||||||
| 8 | Driving Method | 1/30 Scan | ||||||||||
| 9 | Driving IC | MBI5153 | ||||||||||
| 10 | Brightness | 600cd/㎡ | ||||||||||
| 11 | Contrast | 1000:1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜950W | ||||||||||
| 14 | Average power: ＜350W | |||||||||||
| 15 | Module Weight | 0.45kg | ||||||||||
| 16 | Color Temperature | 2000K—12000K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 10 or 14bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >3840Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 85-264V | ||||||||||
| 36 | Protection Level | IP41 | ||||||||||
Our service
1. Your inquiry related to our products or price will be replied in 2hrs
2. OEM customized products
3. 2 years warranty
4. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
5.Free technician training..
6.Top quality+Reasonable price+Responsible After Service=Successful & Win
Products exchanged or returned :
we supply our products strictly according to the contract list , if the quantity or specification doesn't meet our contract list, the buyer can give objections within 3 days after received the products , we’ll exchanged after company confirmed.
Casual damage situation:
We can provide corresponding fittings without extra fee when improper operation or unexpected artificial damaged arise .
Over Guarantee time :
You only have to pay maintenance cost such as labor costs , spare parts costs and round-trip costs !
