SMD Triple Technology P4.8 Indoor Rental LED Display
Product Details:
Place of Origin: | CHINA |
Brand Name: | VEGOO |
Certification: | CE ROHS FCC CCC |
Model Number: | VG-SUN88864 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 SQM |
---|---|
Price: | negotiate |
Packaging Details: | flight case,plywood case,carton |
Delivery Time: | 15-30 working days |
Payment Terms: | T/T |
Supply Ability: | 3000 sqm per month |
Detail Information |
|||
Pixel Pitch: | 4.8mm | Density: | 43,200 Pixel/m2 |
---|---|---|---|
Moduel Size: | 288mm×288mm | Cabinet Size: | 576mm×576mm×90mm |
Cabinet Resolution: | 120×120 | Driving IC: | MBI5124 |
Highlight: | P4.8 indoor smd led display,SMD indoor fixed led display |
Product Description
Fast Installation Indoor Rental LED Display P4.8 With SMD Triple Technology
P4 led rental wall product Feature:
- SMD triple technology, the LED display has a wider viewing angle range, looks very soft ;
- Fast installation and maintenance faster than traditional box 10 times ;
- The product is very light and easy to install and transport ;
- Refresh very high and no ghosting, it can reach 3840 HZ, the screen is very clear without jitter ;
- The black lamps will improve the contrast while maintaining high brightness ;
P4.8 Indoor Full color LED Display Specification
Product Name | Specification | ||||||||||
Pixel Pitch | 4.8mm | ||||||||||
Pixel Configuration | 1R1G1B/SMD3528 Black lamp | ||||||||||
Density | 43,200 pixel/m2 | ||||||||||
Moduel Size(L×W)mm | 288mm×288mm | ||||||||||
Cabinet Size(L×W×H)mm | 576mm×576mm×90mm | ||||||||||
Module Resolution | 60×60 | ||||||||||
Cabinet Resolution | 120×120 | ||||||||||
Driving Method | 1/15 Scan | ||||||||||
Driving IC | MBI5124 | ||||||||||
Brightness | 800cd/㎡ | ||||||||||
Contrast | 1000:1 | ||||||||||
Brightness Adjustment | Auto and Manual | ||||||||||
Power Consumption | Max Power:<400W | ||||||||||
Average power: <150W | |||||||||||
Cabinet Weight | 7.5kg | ||||||||||
Color Temperature | 2000K—9500K | ||||||||||
Horizontal Viewing Angle | 140º | ||||||||||
Vertical Viewing Angle | 140º | ||||||||||
Signal Processing | 16bit | ||||||||||
Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
Frame Frequency | 65 Hz | ||||||||||
Refresh Rate | >1920Hz | ||||||||||
Control Mode | Synchronous/Asynchronous | ||||||||||
The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
MTBF | >50000 hours | ||||||||||
Life Span | 100,000 Hours | ||||||||||
Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
Storage : -40 - 85 ℃ | |||||||||||
Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
Power Supply | AC 110-220V/5V60Hz | ||||||||||
Protection Level | IP 45 |
Our company:
Shenzhen Vegoo electrinic co.,ltd. was founded in 2016, a workshop covering an area of 9000 square meters and independent living and production places.
Customer satisfaction is our prime objective and our high quality LED video display screen used in more than 140 countries and win a high reputation.
Our company offers user-friendly products that optimize productivity and business efficiency and maintain the highest standards of design and quality.
Why choose us:
- Attractive price! If you have any urgent questions, pls contact me without hesitation;
- New product exploring ;
- Energy saving, low power consumption and long lifespan 10,000 hours (about 10 years);
- On time delivery + patient after-sales service;
- Engineer guide install and operate online;
