High Gray Scale Backlit P3 Indoor Full Color LED Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | VEGOO |
| Certification: | CE ROHS FCC CCC |
| Model Number: | VG-SUN88863 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | negotiate |
| Packaging Details: | flight case,plywood case,carton |
| Delivery Time: | 15-30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Pixel Pitch: | 3mm | Density: | 111,111pixel/m2 |
|---|---|---|---|
| Moduel Size: | 192mm×192mm | Cabinet Size: | 576mm×576mm×90mm |
| Cabinet Resolution: | 192×192 | Driving Method: | 1/32 Scan |
| Highlight: | P3 indoor led display board,Backlit smd led display |
||
Product Description
High Gray Scale Indoor Backlit LED Display Screen P3 With Back And Front Service
Advantage:
- Small order accepted;
- Professional lock design makes seamless connection available;
- Better color performance, higher contrast and refresh ratio,high luminance and definition;
- Adjustable brightness: LED screen brightness can be adjusted automatic and manual according to environment light;
- Noiseless:The aluminum structure requires no fan.Combined with the noiseless power supply,the cabinet is totally silent;
- Easy to maintain:No need to disassemble the whole screen for maintenance. Each component can be detached individually;
- professional technical support + quality promise;
P3 Indoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 3mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
| Density | 111,111pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 192mm×192mm | ||||||||||
| Cabinet Size(L×W×H)mm | 576mm×576mm×90mm | ||||||||||
| Module Resolution | 64×64 | ||||||||||
| Cabinet Resolution | 192×192 | ||||||||||
| Driving Method | 1/32 Scan | ||||||||||
| Driving IC | FM6124 | ||||||||||
| Brightness | 800cd/㎡ | ||||||||||
| Contrast | 1000:1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜545W | ||||||||||
| Average power: ＜165W | |||||||||||
| Cabinet Weight | 9.5kg | ||||||||||
| Color Temperature | 2000K—9500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 16bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >1920Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110-220V/5V60Hz | ||||||||||
| Protection Level | IP 45 | ||||||||||
Why choose us:
- Because we have provide 1-3 year warranty ,good after-sale service and timely technical support；
- Many pitches are available from high cost to low cost You can choose according to your budget and the project requirements;
- Many produce lines work everyday for domestic and international orders;
- Stable Good quality:we are led display manufacturer and we have rich experience for outdoor and indoor led screen;
- all of our led module has highly resolution, good image effect,and easy to install and convenient to carry;
- We are factory manufacturer and we control our cost very well we can give the real benefits to our customers;
Want to Know more details about this product
