Product Details:

Place of Origin: CHINA
Brand Name: VEGOO
Certification: CE ROHS FCC CCC
Model Number: VG-SUN88859

Payment & Shipping Terms:

Minimum Order Quantity: 1 SQM
Price: negotiate
Packaging Details: flight case,plywood case,carton
Delivery Time: 15-30 working days
Payment Terms: T/T
Supply Ability: 3000 sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 2.604mm Module Size: 250mm×250mm
Pixels Density: 147,456 Pixel/m2 Weight: 7.5kg
Cabinet Size: 500mm×500mm×90mm Brightness: 800CD/㎡
High Light:

800CD/㎡ screen stage background


P2.604 led display stage

Best Selling Quality Indoor P2.604 Led Screen Stage For Video And Advertising





1,seamless splicing,quickly installation


2,video surveillance


P2.604 Indoor Full color LED Display Specification


Product Name Specification
Pixel Pitch 2.604mm
Pixel Configuration 1R1G1B/SMD2121 Black lamp
Density 147,456 pixel/m2
Moduel Size(L×W)mm 250mm×250mm
Cabinet Size(L×W×H)mm 500mm×500mm×90mm
Module Resolution 96×96
Cabinet Resolution 192×192
Driving Method 1/24 Scan
Driving IC FM6353
Brightness 800CD/㎡
Contrast 1000:01:00
Brightness Adjustment Auto and Manual
Power Consumption Max Power:<600W
Average power: <300W
Cabinet Weight 7.5kg
Color Temperature 2000K—9500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 16bit
Grey Processing 1024×1024×1024
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >3840Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 110-220V/5V60Hz
Protection Level IP 45



Video Advertising 800CD/㎡ P2.604 LED Stage Display Screen 0


packaging and shipping


Carton box:It is the cheapest packing method for the led display,which is mainly for the small screen and short shipping distance.

Wooden case:Wooden case is only for one time using transportation. After unpack, it cannot be used any longer. For the fixed installation ledpanel system, wooden case packing is the only way and the best way for packing since the low cost and same safety level for one timeusing..


Flight case: has wheels and handles which is for the rental use led display, to make the transportation be very convenient and protect the led display better..if your led display screen system is for the rental use, please choose the flight case for your led display screen.



company information


1.Our company owns a group of high-quality professional and technical personnel and advanced modern sophisticated production equipment.


2.We implement strict quality management, making every LED module,LED display cabinet,Power supply ,Video processor ,LED display into competitive products, etc.





1, What is our warranty

Our warranty from 3 year to 1 years basis on different type led screen, In usually every screen we will ready more extra led screen modules as spare modules, if some modules happen fails, you can replace the fail modules by our spare modules, When all the spare modules use out, You can send back these modules to us for repair, and we will send to you after repair and testing&aging well


2,How to be our distributor

To be our distributor, We can share our profit together with you in every year, Also we can send our engineer or sales to your company to support your business, also for led screen after-service, We will together with you to the after-service in the whole led screen life time


3,How to maintence led screen

In usually every year to maintence led screen one time, Clear the led mask, checking the cables connection, if any led screen modules fail, You can replace it with our spare modules
