Waterproof Fixed P10 320×160 Outdoor Fixed LED Video Wall
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/CCC |
| Model Number: | VG-P10-DH3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | negotiation |
| Packaging Details: | Plywood case / Flight case / Carton |
| Delivery Time: | 5-25 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3000Sq.m |
|
Detail Information |
|||
| Product Name: | Outdoor LED Display | Pixel Pitch: | 10mm |
|---|---|---|---|
| Moduel Size(L×W)mm: | 320×160 Or 160×160 | Cabinet Size(L×W×H)mm: | 960×960×130 |
| Contrast: | 7000 ：1 | Brightness: | 7500cd/㎡ |
| High Light: | 320×160 led module p10 outdoor,P10 smd led display |
||
Product Description
Super Waterproof Fixed Led Display Easy Install Energy Saving Fixed Led Screen P10outdoor Fixed Led Video Wall Street Ad
Product Function
Stable performance,wide applicability, high brightness, superb performance/price ratio.
1.High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown.
2.Superb performance/price ratio offers you both top notch quality and reasonable price, maximizing the value of your investment.
| P10 Outdoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 10mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD3535 | ||||||||||
| 3 | Density | 10,000 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 320mm×160mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 960mm×960mm×130mm | ||||||||||
| 6 | Module Resolution | 32×16 | ||||||||||
| 7 | Cabinet Resolution | 96×96 | ||||||||||
| 8 | Driving Method | 1/ 2 Scan | ||||||||||
| 9 | Driving IC | FM6124 | ||||||||||
| 10 | Brightness | 7500CD /㎡ | ||||||||||
| 11 | Contrast | 7000 :1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power: ＜745W | ||||||||||
| 14 | Average power: ＜350W | |||||||||||
| 15 | Cabinet Weight | 28kg | ||||||||||
| 16 | Color Temperature | 2000K—9500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 16bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >1920Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC110-220V/5V60Hz | ||||||||||
| 36 | Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
Good service After-sale
1.Two years warranty for the whole system except human factor and force majeure
2.One year quality warranty, lifetime maintenance, and guarantee the maintenance time in contract.
3.During the warranty period: solve problems for users through the phone, fax or E-Mail. Update the software free of charge.
4.As to the product quality problems caused by design, manufacture, installation technology, material, the replacement and maintenance are free. The system damage caused by force majeure(flood, fire, earthquake, war and so on) as well as users) man-made disturbance(construction, cleaning ) should be coordinate by both sides to solve.
5.Life-long maintenance for the system: after the guarantee, we only charge the cost of hardware.
