Wide Viewing Angle P1.56 140º Indoor LED Video Screens

China Wide Viewing Angle P1.56 140º Indoor LED Video Screens supplier
Wide Viewing Angle P1.56 140º Indoor LED Video Screens supplier Wide Viewing Angle P1.56 140º Indoor LED Video Screens supplier

Large Image :  Wide Viewing Angle P1.56 140º Indoor LED Video Screens

Product Details:

Place of Origin: CHINA
Brand Name: VEGOO
Certification: CE ROHS FCC CCC
Model Number: VG-SUN88846

Payment & Shipping Terms:

Minimum Order Quantity: 1 SQM
Price: negotiate
Packaging Details: flight case,plywood case,carton
Delivery Time: 15-30 working days
Payment Terms: T/T
Supply Ability: 3000 sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 1.56mm Module Size: 150mm×168.75mm×10mm
Cabinet Size: 600mm×337.5mm×38mm Density: 409,600 Pixel/m2
Driving Method: 1/54 Scan Cabinet Resolutio: 384×216
High Light:

140º panel led screen


P1.56 led video panel wall

High Resolution Indoor LED Video Screens P1.56 Wide Viewing Angle Low Consumption


Product advantages


1.Ultra wide viewing angle, the pictures of each angle are even, clear and natural.


2. Low reflective, with black fog lamp and corrugated light absorbing mask, the reflection is small in bright light environment, and the picture is still clear and visible.


3. High contrast, high quality black lamp and corrugated light absorbing sub black surface, clear and sharp image, bright and bright color.

4.Using simple die-casting aluminium cabinet, light and elegant appearance , quick and easy loading and unloading

5.Common good,flexible and easy to use,rental and fixed installation,a wide use range.



P1.56 Indoor Full color LED Display Specification



Product Name Specification
Pixel Pitch 1.56mm
Pixel Configuration 1R1G1B/SMD1010 Black lamp
Density 409,600 pixel/m2
Moduel Size(L×W)mm 150mm×168.75mm×10mm
Cabinet Size(L×W×H)mm 600mm×337.5mm×38mm
Module Resolution 98×108
Cabinet Resolution 384×216
Driving Method 1/54 Scan
Driving IC MBI5153/ICN 2153/FM6353
Brightness 200-500/㎡
Contrast 6000 :1
Brightness Adjustment Auto and Manual
Power Consumption Max Power:<800W
Average power: <100-300W
Cabinet Weight 5kg
Color Temperature 2000K—9500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 16bit
Grey Processing 1024×1024×1024
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >3840Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 110-240V/5V60Hz
Protection Level IP45



Wide Viewing Angle P1.56 140º Indoor LED Video Screens 0


Our goods are packed with wooden case, flight case or according customer's request. Usually fixed installation led display use wooden case and die casting rental led display use flight case.
Carton box:It is the cheapest packing method for the led display,which is mainly for the small screen and short shipping distance. Wooden case:Wooden case is only for one time using transportation. After unpack, it cannot be used any longer. For the fixed installation ledpanel system,
Wooden case packing is the only way and the best way for packing since the low cost and same safety level for one timeusing..
Flight case: has wheels and handles which is for the rental use led display, to make the transportation be very convenient and protect the led display better..if your led display screen system is for the rental use, please choose the flight case for your led display screen. Delivery Within 15-25 days after receiving deposit. If your order is very urgent, you should make it clear for us to prepare..
Q1. Can I have a sample order?
A: Yes, we accepted sample order for your quality test. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 5-7 days, mass production time needs 12-25 days.
Q3. Do you have any MOQ limit for led screen order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: As the product is heavy,so we advise shiped by sea,it depends on your choose.
Q5. How to proceed an order for led display?
A: Firstly let us know your requirements or application, liking project size, rental or fixed installation.Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the order and places deposit for formal order. Fourthly We arrange the finished display cabinet.
Q6. Do you offer guarantee for the products?
A: Yes, we offer 1-3 years warranty to our product
