Small Pitch P1.25 600mm×337.5mm Indoor Full Color LED Display
Product Details:
| Place of Origin: | China |
| Brand Name: | VEGOO |
| Certification: | CE ROHS FCC CCC |
| Model Number: | VG-SUN88845 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | negotiate |
| Packaging Details: | flight case,plywood case,carton |
| Delivery Time: | 15-30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Pixel Pitch: | 1.25mm | Density: | 640,000 Pixel/m2 |
|---|---|---|---|
| Moduel Size: | 150mm×168.75mm | Cabinet Size: | 600mm×337.5mm×38mm |
| Driving Method: | 1/45 Scan | Brightness: | 200-500CD/㎡ |
| Highlight: | P1.25 led advertising panels,600mm×337.5mm light panel video |
||
Product Description
Small pitch P1.25 Indoor Rental LED Display Video Screen With 600mm×337.5mm Cabinet
Our Core Advantage:
1.Die-casting aluminum case
2.Ultra-thin and ultra-light
3.Higher refresh rate,to show a more perfect viewing effect ;
P1.25 Indoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 1.25 mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD1010 Black lamp | ||||||||||
| Density | 640,000 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 150mm×168.75mm×10mm | ||||||||||
| Cabinet Size(L×W×H)mm | 600mm×337.5mm×38mm | ||||||||||
| Module Resolution | 120×135 | ||||||||||
| Cabinet Resolution | 480×270 | ||||||||||
| Driving Method | 1/45 Scan | ||||||||||
| Driving IC | MBI5153 | ||||||||||
| Brightness | 200-500CD/㎡ | ||||||||||
| Contrast | 6000 :1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜800W | ||||||||||
| Average power: ＜100-300W | |||||||||||
| Cabinet Weight | 5kg | ||||||||||
| Color Temperature | 2000K—9500K | ||||||||||
| Horizontal Viewing Angle | 140 | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 16bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >3840Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -10 - 60 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -10℃ to 60℃; humidity Rh10% to 90% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsXP/7/8/10 | ||||||||||
| Power Supply | AC 110V-240V/ 50-60Hz | ||||||||||
| Protection Level | IP 45 | ||||||||||
Our Service:
We will responsible for our product and customers,during the warrenty,we will free to repair if this is our quality problem.
We are always quality first and refuse to do low-quality product.
FQA:
Q1: The warrenty time for the products?
A1: 1-3 years
Q2: The delivery time of the product?
A2: Normally 7-25days after deposit.
Q3: How to install the led video screen?
A3: The insruction manual is needed,and also online guide 24hours.
Q4: What is the payment term?
A4: 30% deposit in advance, and the rest 70% before delivery.
