Module 250mm×250mm 800cd/㎡ Indoor Rental LED Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | VEGOO |
| Certification: | CE ROHS FCC CCC |
| Model Number: | VG-SUN88844 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | negotiate |
| Packaging Details: | flight case,plywood case,carton |
| Delivery Time: | 15-30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Pixel Pitch: | 2.976mm | Density: | 112,896 Pixel/m2 |
|---|---|---|---|
| Moduel Size: | 250mm×250mm | Cabinet Size: | 500mm×500mm×90mm |
| Driving Method: | 1/28 Scan | Brightness: | 800cd/㎡ |
| Highlight: | 800cd/㎡ led panel video screen,250mm×250mm led wall panel system |
||
Product Description
High Resolution Indoor Rental LED Display Led Screen With 250mm×250mm Module
Our Core Advantage:
1.High-strength die-cast aluminum case
2.The cabinet is ultra thin and ultralight
3.High-grade adjustment of the locks makes the installation fast and can adjust the gap between the cabinets ;
4.Higher refresh rate, in the stage show when there is no ripple, to show a more perfect effect ;
5.Product input interface include S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA ;
6.Good thermal design, the screen body running very quiet .
P2.976 Indoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 2.976mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
| Density | 112,896 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 250mm×250mm | ||||||||||
| Cabinet Size(L×W×H)mm | 500mm×500mm×90mm | ||||||||||
| Module Resolution | 84×84 | ||||||||||
| Cabinet Resolution | 168×168 | ||||||||||
| Driving Method | 1/28 Scan | ||||||||||
| Driving IC | FM6353 | ||||||||||
| Brightness | 800cd/㎡ | ||||||||||
| Contrast | 1000:1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜440W | ||||||||||
| Average power: ＜220W | |||||||||||
| Cabinet Weight | 7.5kg | ||||||||||
| Color Temperature | 2000K—9500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 16bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >3840Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110-220V/5V60Hz | ||||||||||
| Protection Level | IP 45 | ||||||||||
Our Service:
We use high-grade LED lamps and driver ICs to ensure product quality ;
Our products have CE, RoHS, FCC, UL and ISO9001 certification ;
We are a professional manufacturer, providing first class service ;
We offer free skills training for our customers forever .
FQA:
Q1: Do you offer the guarantee for the products?
A1: Yes, we offer 1-3 years warranty to our products.
Q2: Whats your delivery time?
A2: Within 7-25 days after we receiving the deposit.
Q3: How to install led display?
A3: We will provide the insruction manual to you,and also online guide anytime.
Q4: What is the payment term?
A4: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.
