Waterproof IP65 P6 SMD LED Advertising Display

China Waterproof IP65 P6 SMD LED Advertising Display supplier
Waterproof IP65 P6 SMD LED Advertising Display supplier Waterproof IP65 P6 SMD LED Advertising Display supplier Waterproof IP65 P6 SMD LED Advertising Display supplier Waterproof IP65 P6 SMD LED Advertising Display supplier Waterproof IP65 P6 SMD LED Advertising Display supplier Waterproof IP65 P6 SMD LED Advertising Display supplier Waterproof IP65 P6 SMD LED Advertising Display supplier

Large Image :  Waterproof IP65 P6 SMD LED Advertising Display

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE
Model Number: VG-P8-DH3

Payment & Shipping Terms:

Minimum Order Quantity: 1sqm
Price: $500/Sqm
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 10-20 days
Payment Terms: T/T
Supply Ability: 5000 Sqm/month
Contact Now
Detailed Product Description
Pixel Pitch: 6mm Moduel Size(L×W)mm: 192mm×192mm
Cabinet Size(L×W×H)mm: 960mm×960mm×130mm Color: Full Color
High Light:

IP65 p6 led display

,

P6 outdoor led screen hire

,

SMD p6 outdoor led screen

P6 SMD Outdoor fixed led advertising display waterproof led screens high brightness led video wall for sign billboard



1. High refresh rate: led billboard With NOVA STAR control system, no scanning line when photographed.
2. High gray level: 256 RGB each ,led panel display 16.7M colors ,vivid and perfect video effect .
3.High resolution: The most apparent features of the new generation of LED sign.
4.Good color uniformity: With brand Lamp Nationstar and high refresh MBI5124 IC.
5. High Brightness: 6000-8000 cd/m2 ,brightness automatically adjusted.
6. High Quality: CE, RoHs, FCC,IP65, passed + 96 Hours serious testing time.
7. Long life span: over100,000hours, warranty 2 years.



P6 Outdoor Full color LED Display Specification
NO: Product Name Specification
1 Pixel Pitch 6mm
2 Pixel Configuration 1R1G1B/SMD3535
3 Density 27,777 pixel/m2
4 Moduel Size(L×W)mm 192mm×192mm
5 Cabinet Size(L×W×H)mm 960mm×960mm×130mm
6 Module Resolution 32×32
7 Cabinet Resolution 160×160
8 Driving Method 1/8 Scan
9 Driving IC FM6124
10 Brightness 6500cd/㎡
11 Contrast 6000 :1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:<810W
14 Average power: <405W
15 Cabinet Weight 25kg
16 Color Temperature 2000K—9500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 16bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V/5V60Hz
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



Waterproof IP65 P6 SMD LED Advertising Display 0

Waterproof IP65 P6 SMD LED Advertising Display 1

Waterproof IP65 P6 SMD LED Advertising Display 2

Waterproof IP65 P6 SMD LED Advertising Display 3



FAQ
Q1:Are you a factory or just a trade company?

A1:Vegoo is a led display factory with R&D department and production line,professional engineering team and energetic sales team.Warmly welcome to visit our HONGHUI factory and have face-to-face business talk to better understand each other .
Q2: What's the warranty of your LED Display ?

A2: 2 years warranty .and 96360hours life span.During the warranty period ,we can offer you related after-sales service. Our professional engineering team are ready for your question during 6:00-23:30.
Q3: What's your payment term? How long is your delivery time ?

A3: We accept T/T ,At least 30-50 % deposit in advance, and the balance should be paid before delivery.Our average Production time is 7-15 working days after receiving the deposit.If your order is rapidly urgent ,we can arrange your order firstly.
Q4:How can I get technical support?

Q4: We treasure every customer that shake hands with our HONGHUI . We offer you TEAMVIEWER help by Online Video and can send professional engineer to your city to offer on-site guide .
Q5: What about your service?

A5: We have a professional 8 years technical team answering your question during 6:00-23:30. We have an energetic and patient sales team.We can offer a complete LED design solution for your LED project before confirming the order.
We can instruct you how to use, configure your led display , and do some maintenance with spare parts.
Also, we can send professional engineer to your city to offer on-site guide and offer training.Mostly,our led display do not have big problems within warranty time.
Q6: Is Available to print customer required logo on your led product ?

A6: Surely it is .Please inform and confirm the logo design details with our team ahead of the production . Then ,we will follow your requirements
