Asynchronous P3.98 576*576 Outdoor Rental Led Display

Asynchronous P3.98 576*576 Outdoor Rental Led Display

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/CCC
Model Number: VG-SUN88825
Document: Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity: 1sqm
Price: $830
Packaging Details: Plywood case / Flight case / Carton
Delivery Time: 7-25 working days
Payment Terms: L/C, T/T
Supply Ability: 5000 Sqm/month
Get Best Price Contact Now

Detail Information

Pixel Pitch: 3.98mm Moduel Size(L×W)mm: 192mm×192mm
Cabinet Size(L×W×H)mm: 576mm×576mm×90mm IP Rate: IP65
Usage: Outdoor Advertising,Stage Led Screen
Highlight:

P3.98 rgb pixel panel

,

576*576 led panel board

Product Description

P3.98 Outdoor Rental Led Display Screen Billboard 576*576 Outdoor Advertising Display Stage Led Screen



P3.98 Outdoor Full color LED Display Specification
NO: Product Name Specification
1 Pixel Pitch 3.98mm
2 Pixel Configuration 1R1G1B/SMD1921
3 Density 62,500 pixel/m2
4 Moduel Size(L×W)mm 192mm×192mm
5 Cabinet Size(L×W×H)mm 576mm×576mm×90mm
6 Module Resolution 48×48
7 Cabinet Resolution 144×144
8 Driving Method 1/12 Scan
9 Driving IC ICN2038S
10 Brightness 4500/㎡
11 Contrast 5000 :1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:<810W
14 Average power: <400W
15 Cabinet Weight 9.5kg
16 Color Temperature 2000K—9500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 16bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V/5V60Hz
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



Asynchronous P3.98 576*576 Outdoor Rental Led Display 0

Asynchronous P3.98 576*576 Outdoor Rental Led Display 1

Asynchronous P3.98 576*576 Outdoor Rental Led Display 2



FAQ



Q1: What's the warranty of your LED Display Screen ?

A1: We have a 2-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

Q2: What about your pre-sale service and post-sale service?

A2: For pre-sale service: We have a professional sales team and a 12 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!



For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.

Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!



Q3: Whats your payment term? How long it takes to delivery?



A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.



Our average Production time is 16 days, after receiving the deposit.

Q4: What's the control system?

A4: For synchronization control: We use Nova, Linsn Or Colorlight control system.

For asynchronous control: We use Huidu, or Xixun control system.

Q5: How can you ensure the led display product quality?

A5: Our led display screen quality is our core competence, for 12 years, what we rely on.

We have each stardard process to make quality products.
