Truck Trailer IP65 P8 Mobile Advertising LED Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE |
| Model Number: | VG-p8-DH |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 10-20days |
| Payment Terms: | T/T |
| Supply Ability: | 5000sqm/month |
|
Detail Information |
|||
| Pixel Pitch: | 8mm | Density: | 15,625 Pixel/m2 |
|---|---|---|---|
| Moduel Size(L×W)mm: | 256mm×128mm | Cabinet Size(L×W×H)mm: | 512mm×512mm×90mm |
| Cabinet Weight: | 6.5kg | Horizontal Viewing Angle: | 140º |
| Highlight: | P8 led billboard truck,IP65 mobile led billboard |
||
Product Description
Mobile truck /trailer advertising P8 Full Color Outdoor Waterproof IP65 truck mobile advertising led display
Product Features:
1.Four small holes on front surface of module for dismounting;Install and maintain conveniently and fastly;
2.Front access module is easier to do maintenance work and no need maintenance corridor,thickness of the whole screen can be very small.
3.Modules are magnetic which can be mount and dismount from cabinet very quickly.
4.Just need 3seconds with simple tools to take down the module from front.
5.Could do pixel level repair,low human cost;Seamless spliced,with smooth and vivid visual effect,perfect performance;
6.Suit outdoor environment,waterproof,durlable,nice cooling systern.
7. Can be flexibly bended in an s-shape and adapt to various installation environments like flat surface, curved surface, etc;
8.High quality, producing according to the international standard of CE,FCC
| P8 Outdoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 8mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD3535 | ||||||||||
| 3 | Density | 15,625 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 256mm×128mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 512mm×512mm×90mm | ||||||||||
| 6 | Module Resolution | 32×16 | ||||||||||
| 7 | Cabinet Resolution | 64×64 | ||||||||||
| 8 | Driving Method | 1/ 4 Scan | ||||||||||
| 9 | Driving IC | FM6124 | ||||||||||
| 10 | Brightness | 5500cd/㎡ | ||||||||||
| 11 | Contrast | 6000 :1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜800W | ||||||||||
| 14 | Average power: ＜350W | |||||||||||
| 15 | Cabinet Weight | 6.5kg | ||||||||||
| 16 | Color Temperature | 2000K—9500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 16bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >1920Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 110-220V/5V60Hz | ||||||||||
| 36 | Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
FAQ:
1. Can we make any size of led display?
YES, but we suggest you take large size because it is better for outdoor advertising
2, How to install led display?
We will provide detailed drawing of installation frame or do Teamviewer to help you install.
3 ,How to ship?
Normally, the display will be shipped by sea because it is much cheaper than by air.
4, Can I buy truck from you?
Yes, but we still suggest you buy at local . Firstly it can save you much more freight cost .
Secondly, the truck from China might be hard to meet your country's emission stardard.
5, Can I play different content on three sided display.
Yes, we will prepare you NOVA software by which you can set up three display windows and then upload different videos on them.
6, why do I need a video processor?
A video processor is a special component that scales and formats the video signal from a media player, satellite receiver, DVD player, computer,or video game console and converts it into a format that can be displayed on an LED screen.
Better quality video processors include hardware and software that enhances image quality and also include multiple inputs so you can switch between several different video sources.
7, Can I do live-streaming ?
Yes , we will prepare a video processor that can realize your thoughts
8, What do I need except a truck and LED display screens?
(1). One set of video processor , light sensor.
(2). One set of diesel generator.
(3). One set of computer
(4). Four sets of speakers.
(5). One set of amplifier.
