P2 P2.5 P3 P4 Indoor Full Color LED Display Screen Video Wall High Refresh Rate
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE |
| Model Number: | p3-dh |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 8000 sqm per month |
|
Detail Information |
|||
| Pixel Pitch: | 2mm | Density: | 250,000 Pixel/m2 |
|---|---|---|---|
| Moduel Size(L×W)mm: | 128mm×128mm | Cabinet Resolution: | 256×256 |
| High Light: | indoor full color led display screen,indoor advertising led display |
||
Product Description
| P2.0 Indoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 2.0mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD1515 Black lamp | ||||||||||
| 3 | Density | 250,000 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 128mm×128mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 512mm×512mm×90mm | ||||||||||
| 6 | Module Resolution | 64×64 | ||||||||||
| 7 | Cabinet Resolution | 256×256 | ||||||||||
| 8 | Driving Method | 1/32 Scan | ||||||||||
| 9 | Driving IC | MBI5153/ICN2153/FM6353 | ||||||||||
| 10 | Brightness | 600CD/㎡ | ||||||||||
| 11 | Contrast | 6000 :1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜915W | ||||||||||
| 14 | Average power: ＜275W | |||||||||||
| 15 | Cabinet Weight | 7.5kg | ||||||||||
| 16 | Color Temperature | 6000K—9000K | ||||||||||
| 17 | Horizontal Viewing Angle | 120º | ||||||||||
| 18 | Vertical Viewing Angle | 120º | ||||||||||
| 19 | Signal Processing | 16bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >3840Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 110-220V/5V60Hz | ||||||||||
| 36 | Protection | IP 45 | ||||||||||
What's the pixel pitch for Outdoor LED Display Screen?
Outdoor (P3mm/P3.91mm/P4mm/P4.81mm/P5mm/P6mm / P8mm/P10mm/P16mm)
What's the pixel pitch for Indoor LED Display Screen?
Indoor (P1.667mm/P1.923mm/P2mm/P2.5mm/P3mm/P3.91mm/P4mm/P4.81mm/P5mm/P6mm / P8mm/P10mm)
What's Packing List for my Order?
LED Module: Come With Flat Cable, Power cable, (Outdoor Rubber Ring)
LED Screen: Come With cabinet, power supply, led Receive Card, Power Cord, Signal Cable between Cabinet.
Sending card or LED Video Processor(as Customer choose, Linsn, Novastar, Colorlight or Huidu)
Why Shipping Cost is so expensive?
Usually shipping by Express is expensive, buyer can contact seller to check on-time shipping cost for Express, Air, Sea cost.
What's Delivery Time?
Usually Common Product have Stock, shipping out within 7 days after deposit.
Customized product need 10~20 days after getting deposit according to the project size.
How about your service?
Lifetime free maintenance and upgrade in Our Factory.
Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
Free technician training and Support.
Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
Special service for big project, such as stadium, exhibitions, squares and so on.
How can you ensure the led display product quality?
A: Our led display screen quality is our core competenc, We will have 3 times Quality test before shipment,If any quality failures within warranty time, we will refund you on alibaba or send new parts to you.
How to choose a proper led screen for you?
A:You just need to think of 3 simple questions in your head before you buy a led screen.
l Will you use it indoor or outdoor?
l Is it for rental use(need to be moved from one place to another place very often) or for fixed installation (to be installed in one place for ever).
lwhat is the approximate size of the led screen you needed? what is the height and length?
How to install it after we receive it?
A: We will offer instructions to guide you on installation, and also software setting up photos or steel construction drawings.
