Indoor LED Display Pixel Pitch 2mm High Definition , Full Color High Brightness
Product Details:
Place of Origin: | CHINA |
Brand Name: | VEGOO |
Certification: | ROHS CE FCC |
Model Number: | VG-P2.0 IM9 |
Payment & Shipping Terms:
Minimum Order Quantity: | Negotiable |
---|---|
Price: | Negotiable |
Packaging Details: | 650 x 650 x 90cm |
Delivery Time: | 12working days |
Payment Terms: | T/T |
Supply Ability: | 3000sqm per month |
Detail Information |
|||
Usage: | Indoor | Screen Dimension: | Customized Size |
---|---|---|---|
Led Chip: | Nationstar | Refresh Rate: | 1920Hz,3840HZ |
Cabinet Weight: | 7kg | Power Supply: | 50~60Hz,G-energy |
Pixel Density: | 250000Pixel /m2 | Color: | Full-color |
Application: | Live Events Led Display,Indoor Advertising | Warranty: | 3 Years |
Display Function: | Video,Graphics,Animation | Life Span: | 100000 Hours |
Pixels: | 2.0mm | Product Name: | Led Video Display |
Highlight: | full color led display board,indoor advertising led display |
Product Description
NO: Product Name Specification
1 Pixel Pitch 2.0mm
2 Pixel Configuration 1R1G1B/SMD1515 Black lamp
3 Density 250,000 pixel/m2
4 Moduel Size(L×W)mm 128mm×128mm
5 Cabinet Size(L×W×H)mm 512mm×512mm×90mm
6 Module Resolution 64×64
7 Cabinet Resolution 256×256
8 Driving Method 1/32 Scan
9 Driving IC MBI5153
10 Brightness 600CD/㎡
11 Contrast 1000:01:00
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:<1000W
14 Average power: <500W
15 Module Weight 0.21kg
16 Color Temperature 6000K—9000K
17 Horizontal Viewing Angle 120º
18 Vertical Viewing Angle 120º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >3840Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection IP 41
