P4.81 Rental Outdoor Full Color LED Display Event Cabinet 500 Or 1000mm
Product Details:
| Place of Origin: | Made in China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/CCC |
| Model Number: | VGrental |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Flight case,1mx1.2x1m |
| Delivery Time: | 15-25 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sq.m/month |
|
Detail Information |
|||
| Product Name: | Moving Display | Pixel Pitch: | 4.81mm |
|---|---|---|---|
| Pixel Configuration Indoor: | 1R1G1B | Moduel Size(L×W)mm: | 250mm×250mm |
| Cabinet Size 2: | 500mm×500mm | Cabinet Size(L×W×H)mm: | 500mm×1000mm |
| Brightness: | 4500cd/㎡ | Material: | Nation Star LED |
| Material1: | Nova System | Application: | Retal Outdoor |
| Type: | Moving Display Rent Use Indoor And Outdoor | Others: | Curve |
| Color: | Full Color | ||
| Highlight: | outdoor advertising led display screen,outdoor full color led screen |
||
Product Description
P4.81 rental display outdoor event cabinet 500 or 1000mm
1:
Aluminum cabinet photos
500x500mm
Advantages:
Quick Assembly and Disassebmly
Adjustable Angle Lock, Flexible Stage Design
Slim and Light Weight Die Casting Aluminum Cabinet Design
Front Maintenance Magnetic Module
4K HD
Specification
| Shenzhen WeiGu Electronic Technology Co.,Ltd. |
||||||||||||
| Outdoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 4.81mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD2727 | ||||||||||
| 3 | Density | 43,243 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 250mm×250mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 500mm×500mm×90mm | ||||||||||
| 6 | Module Resolution | 52×52 | ||||||||||
| 7 | Cabinet Resolution | 104×104 | ||||||||||
| 8 | Driving Method | 1/13 Scan | ||||||||||
| 9 | Driving IC | MBI5124 | ||||||||||
| 10 | Brightness | 4500cd/㎡ | ||||||||||
| 11 | Contrast | 1000:1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜560W | ||||||||||
| 14 | Average power: ＜320W | |||||||||||
| 15 | Module Weight | 0.663kg | ||||||||||
| 16 | Color Temperature | 9500K—11500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 10 or 14bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >1920Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 110-220V | ||||||||||
| 36 | Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
Service and Guarantees
2 to 5 years guarantees
Techenical support on site
