Indoor LED Display Video Wall / Big LED Screen Pixel Pitch 5MM Full Color Scan 1/16 IC ICN2038S LED Lamp 2121
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | VEGOO |
| Certification: | ISO2000 |
| Model Number: | VG-P5 ID |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negitionable |
| Packaging Details: | 80 * 80 * 100cm |
| Delivery Time: | 15 workding day |
| Payment Terms: | T/T |
| Supply Ability: | 3000M2 per Month |
|
Detail Information |
|||
| Pixel Pitch 5mm Pixel Pitch 5mm: | 5MM | Pixel Configuration: | 1R1G1B/ Black Lamp |
|---|---|---|---|
| Density: | 40000 Pixel/m2 | Screen Dimension: | Customized |
| Warranty: | 3 Years | Brightness: | 1000 Cd/m2 |
| Tube Chip Color: | Full Color | Application: | Live Events Led Display,Indoor |
| Scan Mode: | 1/16scan | Module Resolution: | 64*32 |
| Life Span: | 100000hours | Led Type: | SMD2121 |
| Refresh Rate: | 1920/3840 | ||
| Highlight: | indoor advertising led display,indoor full color led display screen |
||
Product Description
| Pixel Pitch | 5mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD3528 Black lamp | ||||||||||
| Density | 40,000 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 320mm×160mm | ||||||||||
| Cabinet Size(L×W×H)mm | 640mm×640mm×90mm | ||||||||||
| Module Resolution | 64×32 | ||||||||||
| Cabinet Resolution | 128×128 | ||||||||||
| Driving Method | 1/16 Scan | ||||||||||
| Driving IC | MBI5124 | ||||||||||
| Brightness | 800CD/㎡ | ||||||||||
| Contrast | 1000:01:00 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜600W | ||||||||||
| Average power: ＜200W | |||||||||||
| Module Weight | 0.45kg | ||||||||||
| Color Temperature | 9500K—11500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 10 or 14bit | ||||||||||
| Grey Processing | 1024×1024×1024 | ||||||||||
| 16834×16834×16834 | |||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >1920Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110-220V | ||||||||||
| Protection | dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
