4K Digital Indoor Full Color LED Display P0.9 P1.2 P1.5 P1.6 P1.8 P1.9 P2.0 RGB For Indoor
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/CCC |
| Model Number: | VGHDP1.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | USD2200-USD6200/square meter |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 7-25 working days |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 1500Sqm/months |
|
Detail Information |
|||
| Product Name: | 4K Digital LED Pantallas | Pixel Pitch: | 1.25 Mm |
|---|---|---|---|
| Product Pixel Pitch: | P0.9mm P1.2 P1.5 P1.6 P1.8 P1.9 P2.0 | Application: | Indoor High Definition |
| Density: | 640,000 Pixel/m2 | Moduel Size(L×W)mm: | 200mm×150mm×8mm |
| Driving Method: | 1/30 Scan | Driving IC: | MBI5153 |
| Brightness: | 600-800CD/㎡ | Color: | RGB Full Color |
| Applicated: | Conference CCTV Digital | Fetures: | Congress |
| Material: | LED Panel | ||
| High Light: | indoor advertising led display,indoor full color led display screen |
||
Product Description
4K Digital LED pantallas P0.9 P1.2 P1.5 P1.6 P1.8 P1.9 P2.0 RGB full color for indoor high refresh rate
LED Pantallas Display Descrition:
Featuring high brightness, wide viewing angles and stunning picture quality, Perimeter Led Display application is specially designed for exceptional performance in large sports arenas. The extreme durability and new safety features enable Retop's Perimeter Led Display appear to most famous sport arenas worldwide. This state-of-the-art LED perimeter displa
y also boasts a modular, lightweight design with an adjustable stand, creating it even more flexible.
Accident-free: Front surface to protect athletes from injuries; Top part with a special soft protection. Angled LED configuration with tilted foot system for multiple setup scenarios, striking a perfect balance between live audiences and broadcast camera. Multiple uses as both perimeter system and commercial display when stacked.
Specifications
For example P1.25
| Product Name | Specification | ||||||||||
| Pixel Pitch | 1.25 mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD1010 Black lamp | ||||||||||
| Density | 640,000 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 200mm×150mm×8mm | ||||||||||
| Cabinet Size(L×W×H)mm | 400mm×300mm×65mm 4.2KG/cabinet | ||||||||||
| Module Resolution | 160×120 | ||||||||||
| Cabinet Resolution | 320×240 | ||||||||||
| Driving Method | 1/30 Scan | ||||||||||
| Driving IC | MBI5153 | ||||||||||
| Brightness | 600-800CD/㎡ | ||||||||||
| Contrast | 4000 ., 1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜900W | ||||||||||
| Average power: ＜100-300W | |||||||||||
| Module Weight | 0.45kg | ||||||||||
| Color Temperature | 2000K—12000K | ||||||||||
| Horizontal Viewing Angle | 160º | ||||||||||
| Vertical Viewing Angle | 160º | ||||||||||
| Signal Processing | 10 or 14bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >3840Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -10 - 60 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -10℃ to 60℃; humidity Rh10% to 90% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsXP/7/8/10 | ||||||||||
| Power Supply | AC 85-264V | ||||||||||
| Protection Level | IP 41 | ||||||||||
Service Content
1. 24-hour hotline service, including counseling and technical guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training
5. Paid software upgrade.
6. Warranty service.
7. Engineering technical service.
OEM/ODM Customized service
Small order acceptable
Rich Experence Original Manufactory
World Fine Pitch LED Visual Solution Provider
