P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m

China P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m supplier
P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m supplier P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m supplier P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m supplier P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m supplier P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m supplier P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m supplier

Large Image :  P8 Outdoor Full Color LED Display Density 15625dots/M2 High Refresh RateRecommended Viewing Distance 8m-180m

Product Details:

Place of Origin: CHINA
Brand Name: VEGOO
Certification: CE,FCC,ROHS
Model Number: VG-OTD8

Payment & Shipping Terms:

Minimum Order Quantity: 1SQM
Price: 200USD
Packaging Details: 80x 80 x 80 cm
Delivery Time: 15-35days
Payment Terms: Western Union, T/T, MoneyGram
Supply Ability: 3000SQM per month
Detailed Product Description
High Light:

outdoor advertising led display screen

,

outdoor digital signage displays

Key Specifications/Special Features: Product P8 outdoor full color LED video wall Module size :256*128mm Pixel density :15625dots/m² LED lamp :SMD3535 Module resolution: 32*16 Module Viewing distance :8-180m Max power consumption :950W/m² Standard cabinet size:768*768mm Drive mode:1/4scan Brightness:≥6000cd/m² HUB mode:HUB75 Drive IC:FM5020/SM16107 Frame frequency : ≧60Hz/s Refresh rate :≧360Hz/s MTTF: >5000 hours Life time:>100,000 hours Defect rate :<0.0001 Video signal input :RF, S-video, RGB, RGBHV, YUV, YC, composition Temperature range :-20 to 65°C Working:-20 to 50°C Gray scale/color : 4096 grades for R ,G and B



Outdoor Full Color LED Display discription:


1. Rental display; 2. Advertising LED display; 3. LED TV; 4. Full color anomalous display etc. Products are widely used in various public places: Such as commercial plaza, government agency, stadiums, transport facilities, financial institutions, theater, performance hall, etc. Our products are exported to the United States, Europe, southeast Asia and other countries, Hong Kong, Taiwan and other regions. With international standards of production process, strictly control product quality and won the customer consistent high praise.
Through the ways like cooperation with local customers, set up offices in local, WeiGu LED have set up a batch of after-sales service which can rapidly solve problems. For rapid response, to quickly solve customer problem, personalized solutions. Make the products and services reflect personalized, comprehensive, long cycle, less defects. WeiGu LED is located in Shiyan Town, Baoan district, Shenzhen. Positive response national green environmental protection, energy conservation and emission reduction policy in developing process. We continue to focus on the LED display, striving to become the world's highest cost-effective LED supplier, the solution to the overall service, with the attitude of a new high-speed development in LED display industry.

Outdoor Full Color LED Display APPLICATION


Rental,indoor,outdoor,transparent,flexible,accessories.



Outdoor Full Color LED Display Parameters



Type G series G3 LED type SMD1921
NO. Color Iv(mcd)
Typ
Rd(nm)
Typ
1 R(test condition:15mA,2.0V) 350mcd 622nm
2 G(test condition:8mA,3.0V) 620mcd 530nm
3 B(test condition:5mA,3.0V) 95mcd 472nm



1 LED type FM-B1921RGBA-HG
2 Pixel pitch 3mm
3 Pixel configuration 1R1G1B
(2)module technical parameter
1 module resolution(W×H) 53dots×53dots
2 module dimension(W×H×D) 160mm×160mm×28mm
3 mask Flame retardant PVC



(3)control system parameter
1 the processing color depth R,G,B16bit
2 driving method constant current driving 1/13 scan
3 frame rate 60Hz (3D high refresh rate :120Hz)
4 refresh rate Regular refresh rate:900Hz high refresh rate:1920Hz
5 panel color Temp 2000K9500K(adjustable)
6 brightness adjustment manually/Auto/programme control
7 pixel correction point by point correction
8 control method synchronism
9 software interface Windows XP /7/8/10
10 input signal HDMI,DVI
