P16mm Outdoor Full Color LED Display With Synchronous / Asynchronous Control
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/ |
| Model Number: | VG-FD P16 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Packaging Details: | Plywood case / Flight case / Carton box |
|---|---|
| Delivery Time: | 3-5 days |
| Supply Ability: | 3000Sq.m |
|
Detail Information |
|||
| Product Name: | P16 Outdoor Full Color LED Display | Pixel Pitch: | 16mm |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B/DIP 546 | Density: | 3,906 Pixel/m2 |
| Moduel Size(L×W)mm: | 256mm×256mm | Cabinet Size(L×W×H)mm: | 1024mm×1024mm×130mm |
| Driving Method: | Static | Brightness: | 8500cd/㎡ |
| Highlight: | outdoor advertising led display screen,outdoor digital signage displays |
||
Product Description
1. Multivariate Structural Design:
The cabinets can be installed by ground stacking insallation,column installation,hanging insallation and other insallation,and can also be curved switching to meet the various needs of clients effect.
2. Convenient Maintenance Operations:
Disassembling modules without opening back cover.
3. Reliable Protection Class:
Cabinet's protection grade in front sides and real sides all reach IP65,certified through SGS third party.Screen can be used in wind,rain and snow weather.
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 16mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/DIP 546 | ||||||||||
| 3 | Density | 3,906 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 256mm×256mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 1024mm×1024mm×130mm | ||||||||||
| 6 | Module Resolution | 16×16 | ||||||||||
| 7 | Cabinet Resolution | 64×64 | ||||||||||
| 8 | Driving Method | Static | ||||||||||
| 9 | Driving IC | MBI5124 | ||||||||||
| 10 | Brightness | 8500cd/㎡ | ||||||||||
| 11 | Contrast | 1000:1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power: ＜1200W | ||||||||||
| 14 | Average power: ＜550W | |||||||||||
| 15 | Module Weight | 0.8kg | ||||||||||
| 16 | Color Temperature | 9500K—11500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 10 or 14bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >1920Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 110-220V | ||||||||||
| 36 | Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
