High Definition Fireproof P16 Outdoor Led Digital Display 7500cd/㎡
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/ |
| Model Number: | VG-FD P16 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Packaging Details: | Plywood case / Flight case / Carton box |
|---|---|
| Delivery Time: | 3-5 days |
| Supply Ability: | 3000Sq.m |
|
Detail Information |
|||
| Product Name: | P16 Outdoor Full Color LED Display | Pixel Pitch: | 16mm |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B/SMD 3535 | Density: | 3,906 Pixel/m2 |
| Moduel Size(L×W)mm: | 256mm×256mm | Cabinet Size(L×W×H)mm: | 1024mm×1024mm×130mm |
| Module Resolution: | 16×16 | Cabinet Resolution: | 64×64 |
| Driving Method: | Static | Driving IC: | MBI5124 |
| Brightness: | 7500cd/㎡ | Contrast: | 1000:1 |
| Highlight: | outdoor advertising led display screen,outdoor digital signage displays |
||
Product Description
High Definition P16 Outdoor Full color LED Display 7500cd/㎡
Description:
1. Adopting high quality led lamps, higher brightness, lower decay, and larger viewing angle.
2. Taking integrated cabinet design, easy to install and maintenance
3. Fire-proof anti-UV (ultraviolet), resistant to high temperature, acid salt spray;
4. Entire screen is in high contrast, consistent white balance, uniform color display, better picture clarity
5. Using a special mask design, automatic water diversion clean up dust,
IP67 dustproof and waterproof grade, inside sprinkled with Guard lacquer, high corrosion-proof capability
6. Brightness will be adjusted automatically according to external environment, no light pollution
7. Remote control power supply.
8. Two years warranty
9. High performance!
Application:
advertising media, sports stadiums, airport station integrated information dissemination, business establishments, and public square
P16 Outdoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 16mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD 3535 | ||||||||||
| Density | 3,906 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 256mm×256mm | ||||||||||
| Cabinet Size(L×W×H)mm | 1024mm×1024mm×130mm | ||||||||||
| Module Resolution | 16×16 | ||||||||||
| Cabinet Resolution | 64×64 | ||||||||||
| Driving Method | Static | ||||||||||
| Driving IC | MBI5124 | ||||||||||
| Brightness | 7500cd/㎡ | ||||||||||
| Contrast | 1000:1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power: ＜1000W | ||||||||||
| Average power: ＜500W | |||||||||||
| Module Weight | 0.8kg | ||||||||||
| Color Temperature | 9500K—11500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 10 or 14bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >1920Hz | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110-220V | ||||||||||
| Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
