Curve P6 Outdoor Full Color LED Display Large Video Screen Displays

China Curve P6 Outdoor Full Color LED Display Large Video Screen Displays supplier
Curve P6 Outdoor Full Color LED Display Large Video Screen Displays supplier Curve P6 Outdoor Full Color LED Display Large Video Screen Displays supplier

Large Image :  Curve P6 Outdoor Full Color LED Display Large Video Screen Displays

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-FD 6

Payment & Shipping Terms:

Minimum Order Quantity: 1 sq.m
Packaging Details: Flight case
Delivery Time: 10-15 days
Supply Ability: 3000sq.m/month
Detailed Product Description
Product Name: P6 Outdoor Full Color LED Display Pixel Pitch: 6mm
Pixel Configuration: 1R1G1B/SMD3535 Density: 27,777 Pixel/m2
Moduel Size(L×W)mm: 192mm×192mm Cabinet Size(L×W×H)mm: 576mm×576mm×90mm
Brightness: 6500cd/㎡ Contrast: 1000:1
High Light:

outdoor advertising led display screen

,

outdoor full color led screen



curve P6 Outdoor Full color LED Display large video screen displays





Application and function:



Suit for advertisement, stage, stadium, exhibition, TV-Show, mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc.

1. Video display for advertisement

2. Dynamic display for logo, text, video

3. Stage background

4. Live broadcast for news, sport, concert…

5. Information display for time, schedule, text





P6 Outdoor Full color LED Display Specification



NO: Product Name Specification
1 Pixel Pitch 6mm
2 Pixel Configuration 1R1G1B/SMD3535
3 Density 27,777 pixel/m2
4 Moduel Size(L×W)mm 192mm×192mm
5 Cabinet Size(L×W×H)mm 576mm×576mm×90mm
6 Module Resolution 32×32
7 Cabinet Resolution 96×96
8 Driving Method 1/8 Scan
9 Driving IC MBI5124
10 Brightness 6500cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:<545W
14 Average power: <165W
15 Module Weight 0.244kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



Upgrade Service :





Unschedule,we will upgrade our system of products without extra formal; we’ll do our best to help users with upgrading ; the following conditions are excluded by this warranty :

1. Without approved documents;

2. Series code on products having been torn or changed ;

3. Damage caused by lighting strike or electrical problems;

4. Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.

5. Users or third party refit or repaired by themselves without VEGOO’s permission ;

6. Water intrusion or corrosion caused by improper keeping or operating ;

7. Over period of free maintenance .
