High Brightness Outdoor Full Color LED Display P6 Led Module 27777 Pixel/M2

China High Brightness Outdoor Full Color LED Display P6 Led Module 27777 Pixel/M2 supplier
High Brightness Outdoor Full Color LED Display P6 Led Module 27777 Pixel/M2 supplier High Brightness Outdoor Full Color LED Display P6 Led Module 27777 Pixel/M2 supplier

Large Image :  High Brightness Outdoor Full Color LED Display P6 Led Module 27777 Pixel/M2

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-FD 6

Payment & Shipping Terms:

Minimum Order Quantity: 1 sq.m
Packaging Details: Flight case
Delivery Time: 10-15 days
Supply Ability: 3000sq.m/month
Contact Now
Detailed Product Description
Product Name: P6 Outdoor Full Color LED Display Pixel Pitch: 6mm
Pixel Configuration: 1R1G1B/SMD3535 Density: 27,777 Pixel/m2
Moduel Size(L×W)mm: 192mm×192mm Cabinet Size(L×W×H)mm: 576mm×576mm×90mm
Brightness: 6500cd/㎡ Contrast: 1000:1
High Light:

outdoor advertising led display screen

,

outdoor digital signage displays



high Brightness P6 Outdoor Full color LED Display 27777 pixel/m2





Quick Details:



1. 6mm pixel rgb, hd, big density, very bright

2. on-site professional service.

3. hotline service, fast response.

4. 2 years' warranty for entire screen.

5. adequate spare parts supply.

6. technical support on upgrades and replacement.

7. regular maintenance service.





Function and Technology Character:



1. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.

2. Super correcting technology for distortion.

3. Connected and controlled by PC via Lan and remote control.

4. Information source can be camera, video, VCD, DVD, LD, TV and so on.

5. Clear picture without flicker and distortion.

6. Brightness, contrast, saturation can be adjust by itself and manual.

7. Show everything with your PC does synchronously.

8. Multiform language editions, such as English, French, Germany, Greek, Russian and so on

9. One interface for sound signal and two for video signal at least.





P6 Outdoor Full color LED Display Specification



Product Name Specification
Pixel Pitch 6mm
Pixel Configuration 1R1G1B/SMD3535
Density 27,777 pixel/m2
Moduel Size(L×W)mm 192mm×192mm
Cabinet Size(L×W×H)mm 576mm×576mm×90mm
Module Resolution 32×32
Cabinet Resolution 96×96
Driving Method 1/8 Scan
Driving IC MBI5124
Brightness 6500cd/㎡
Contrast 1000:1
Brightness Adjustment Auto and Manual
Power Consumption Max Power:<545W
Average power: <165W
Module Weight 0.244kg
Color Temperature 9500K—11500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 10 or 14bit
Grey Processing 1024×1024×1024
16834×16834×16834
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >1920Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 110-220V
Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)
