sports stadiums P16 Outdoor Full color LED Display 7500cd/㎡

China sports stadiums P16 Outdoor Full color LED Display 7500cd/㎡ supplier
sports stadiums P16 Outdoor Full color LED Display 7500cd/㎡ supplier sports stadiums P16 Outdoor Full color LED Display 7500cd/㎡ supplier

Large Image :  sports stadiums P16 Outdoor Full color LED Display 7500cd/㎡

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-FD P10

Payment & Shipping Terms:

Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 3-5 days
Supply Ability: 3000Sq.m
Detailed Product Description
Product Name: P16 Outdoor Full Color LED Display Pixel Configuration: 1R1G1B/SMD 3535
Moduel Size(L×W)mm: 256mm×256mm Module Resolution: 16×16
Driving Method: Static Driving IC: MBI5124
Brightness: 7500cd/㎡ Contrast: 1000:1
High Light:

outdoor digital signage displays


outdoor full color led screen


1. Large viewing angle, up to 110°horizontally and 60°vertically, with no image distortion and no color cast at any angle within this range.

2. All of the cabinets are tested by flush, shower and soaking, to ensure the waterproof grade in front side to be IP65 and back side to be IP43, and the Highway Display Screen is designed with double-deck door to ensure IP65 for both sides.

3. Good performance in color uniformity.

Advertising media, sports stadiums, airport station integrated information dissemination, business establishments, public square
P16 Outdoor Full color LED Display Specification


NO: Product Name Specification
1 Pixel Pitch 16mm
2 Pixel Configuration 1R1G1B/SMD 3535
3 Density 3,906 pixel/m2
4 Moduel Size(L×W)mm 256mm×256mm
5 Cabinet Size(L×W×H)mm 1024mm×1024mm×130mm
6 Module Resolution 16×16
7 Cabinet Resolution 64×64
8 Driving Method Static
9 Driving IC MBI5124
10 Brightness 7500cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power: <1000W
14 Average power: <500W
15 Module Weight 0.8kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



Our products WeiGu LED displays in the rapidly expanding Chinese market at the same time, has towards the international market, and the share of export gradually increasing. (all of our products passed RoHS/CCC/CE/EMC/ISO /FCC certifications. The LED application product variety is complete which researched and manufactured by our company, the product structure diversifying. Including: Cover the indoor and outdoor series. Such like: 1. Rental display; 2. Advertising LED display; 3. LED TV; 4. Full color anomalous display etc. Products are widely used in various public places: Such as commercial plaza, government agency, stadiums, transport facilities, financial institutions, theater, performance hall, etc. Our products are exported to the United States, Europe, southeast Asia and other countries, Hong Kong, Taiwan and other regions. With international standards of production process, strictly control product quality and won the customer consistent high praise.

Through the ways like cooperation with local customers, set up offices in local, WeiGu LED have set up a batch of after-sales service which can rapidly solve problems. For rapid response, to quickly solve customer problem, personalized solutions. Make the products and services reflect personalized, comprehensive, long cycle, less defects. WeiGu LED is located in Shiyan Town, Baoan district, Shenzhen. Positive response national green environmental protection, energy conservation and emission reduction policy in developing process. We continue to focus on the LED display, striving to become the world's highest cost-effective LED supplier, the solution to the overall service, with the attitude of a new high-speed development in LED display industry.
