1R1G1B/DIP 546 P16 Outdoor Full color LED Display 8500cd/㎡

China 1R1G1B/DIP 546 P16 Outdoor Full color LED Display 8500cd/㎡ supplier
1R1G1B/DIP 546 P16 Outdoor Full color LED Display 8500cd/㎡ supplier 1R1G1B/DIP 546 P16 Outdoor Full color LED Display 8500cd/㎡ supplier

Large Image :  1R1G1B/DIP 546 P16 Outdoor Full color LED Display 8500cd/㎡

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-FD P10

Payment & Shipping Terms:

Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 3-5 days
Supply Ability: 3000Sq.m
Contact Now
Detailed Product Description
Product Name: P16 Outdoor Full Color LED Display Pixel Pitch: 16mm
Density: 3,906 Pixel/m2 Moduel Size(L×W)mm: 256mm×256mm
Module Resolution: 16×16 Cabinet Resolution: 64×64
Brightness: 8500cd/㎡ Contrast: 1000:1
High Light:

outdoor advertising led display screen


outdoor digital signage displays


1. Multivariate Structural Design:

The cabinets can be installed by ground stacking insallation,column installation,hanging insallation and other insallation,and can also be curved switching to meet the various needs of clients effect.


2. Convenient Maintenance Operations:

Disassembling modules without opening back cover.


3. Reliable Protection Class:

Cabinet's protection grade in front sides and real sides all reach IP65,certified through SGS third party.Screen can be used in wind,rain and snow weather.

P16 Outdoor Full color LED Display Specification


NO: Product Name Specification
1 Pixel Pitch 16mm
2 Pixel Configuration 1R1G1B/DIP 546
3 Density 3,906 pixel/m2
4 Moduel Size(L×W)mm 256mm×256mm
5 Cabinet Size(L×W×H)mm 1024mm×1024mm×130mm
6 Module Resolution 16×16
7 Cabinet Resolution 64×64
8 Driving Method Static
9 Driving IC MBI5124
10 Brightness 8500cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power: <1200W
14 Average power: <550W
15 Module Weight 0.8kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



Service and Guarantees


Services Before-sale:Set a special telephone line to resolve the confusion from clients and supply free technology services by telephone.Consider the demands of clients carefully , study the situation of the installation condition , Team up the related staff and workers promptly , give clients design program details to help them choose the products which they wanted as soon as possible


Service In - sales :Try the best to meet the reasonable demands by clients Provisional changed .Keep close touch with the clients during the period if installation .Cooperate friendly with the clients, satisfy the clients with the best quality of led display .


Service After-sale:Normal products have one year guarantee, and whole life maintenance, free charges . we just charge materials cost only if products out off guarantee.You can down load and upgrade the related operating software of Led display freely from our company website , so as to resolve the problems when you use our led display .Check the quality of appliance , do maintenance job and ask good suggestions form clients on a regular time schedule .
