1R1G1B/SMD3535 P10 Outdoor Full color LED Display 320mm×160mm

China 1R1G1B/SMD3535 P10 Outdoor Full color LED Display 320mm×160mm supplier
1R1G1B/SMD3535 P10 Outdoor Full color LED Display 320mm×160mm supplier 1R1G1B/SMD3535 P10 Outdoor Full color LED Display 320mm×160mm supplier

Large Image :  1R1G1B/SMD3535 P10 Outdoor Full color LED Display 320mm×160mm

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-FD P10

Payment & Shipping Terms:

Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 3-5 days
Supply Ability: 3000Sq.m
Contact Now
Detailed Product Description
Product Name: P10 Outdoor Full Color LED Display Pixel Pitch: 10mm
Moduel Size(L×W)mm: 320mm×160mm Module Resolution: 32×16
Cabinet Resolution: 96×96 Driving Method: 1/ 2 Scan
Driving IC: MBI5124 Or ICN 2038S Brightness: 7500CD /㎡
Contrast: 1000:1
High Light:

outdoor advertising led display screen


outdoor full color led screen

Strict quality control procedure:


a.Aging testing:72hours aging testing in high temperature for LED Modules before glue painting and after

QC functional testing, another 72 hours aging testing for LED cabinet before delivery.


b.Waterproof testing: The assembled LED cabinets need to be taken shower comprehensively, and the

f-ront side put into the water. It ensures the Ingress Protection level is up to IP65.


c.Anti-rusting testing:PCB, Screws, and LED cabinets are under salty testing for 24 hours


d.Simulated Vibration test:To avoid the defect during transportation, the Simulated Vibration test has been

conducted before delivery, especially for the Traffic Sign and Truck-Mounted LED Display.


e.The Debugging testing: The debugging testing of the whole screen under a simulated installation

enviro-nment is conducted for ensuring high-quality display performance on the real spot.

P10 Outdoor Full color LED Display Specification


Product Name Specification
Pixel Pitch 10mm
Pixel Configuration 1R1G1B/SMD3535
Density 10,000 pixel/m2
Moduel Size(L×W)mm 320mm×160mm
Cabinet Size(L×W×H)mm 960mm×960mm×130mm
Module Resolution 32×16
Cabinet Resolution 96×96
Driving Method 1/ 2 Scan
Driving IC MBI5124 or ICN 2038S
Brightness 7500CD /㎡
Contrast 1000:1
Brightness Adjustment Auto and Manual
Color Temperature 9500K—11500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 10 or 14bit
Grey Processing 1024×1024×1024
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >1920Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 85-264V
Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)


1R1G1B/SMD3535 P10 Outdoor Full color LED Display 320mm×160mm 0


Service and Guarantees


Services Before-sale:Set a special telephone line to resolve the confusion from clients and supply free technology services by telephone.Consider the demands of clients carefully , study the situation of the installation condition , Team up the related staff and workers promptly , give clients design program details to help them choose the products which they wanted as soon as possible


Service In - sales :Try the best to meet the reasonable demands by clients Provisional changed .Keep close touch with the clients during the period if installation .Cooperate friendly with the clients, satisfy the clients with the best quality of led display .


Service After-sale:Normal products have one year guarantee, and whole life maintenance, free charges . we just charge materials cost only if products out off guarantee.You can down load and upgrade the related operating software of Led display freely from our company website , so as to resolve the problems when you use our led display .Check the quality of appliance , do maintenance job and ask good suggestions form clients on a regular time schedule .
