Professional Remote Control Soft Flexible LED Screen 4mm AC 110V - 220V
Product Details:
Place of Origin: | China |
Brand Name: | Vegoo |
Certification: | CE/ROHS/FCC/ |
Model Number: | VG-SD P4 |
Document: | Product Brochure PDF |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 sq.m |
---|---|
Packaging Details: | Plywood case / Flight case / Carton box |
Delivery Time: | 12-15 days |
Detail Information |
|||
Product Name: | Flexible LED Screen | Pixel Pitch: | 4mm |
---|---|---|---|
Pixel Configuration: | 1R1G1B/SMD2121 Black Lamp | Moduel Size(L×W)mm: | 256mm×128mm |
Cabinet Size(L×W×H)mm: | 512mm×512mm×90mm | Cabinet Resolution: | 128×128 |
Driving IC: | MBI5124 Or ICN 2038S | Contrast: | 1000:1 |
Highlight: | flexible led display,flexible led panel |
Product Description
Professional Soft Flexible LED Screen display AC 110–220V
Description:
1) Strong supply ability: 6000sqm per month LED display production and standard products in stock for quick delivery;
2) Stable quality: Professionally supplied LED screen to over 100 countries and installed thousands projects in 11 yeas;
3) Innovation: According to customer's demands and save more time and cost on the installation, maintenance, and make sure more steady quality and easy operation.
4) Reasonable price: Profit back to customer for long term win-win cooperation;
P4 Indoor Full color LED Display Specification:
Product Name | Specification | ||||||||||
Pixel Pitch | 4mm | ||||||||||
Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
Density | 62,500 pixel/m2 | ||||||||||
Moduel Size(L×W)mm | 256mm×128mm | ||||||||||
Cabinet Size(L×W×H)mm | 512mm×512mm×90mm | ||||||||||
Module Resolution | 64×32 | ||||||||||
Cabinet Resolution | 128×128 | ||||||||||
Driving Method | 1/16 Scan | ||||||||||
Driving IC | MBI5124 or ICN 2038S | ||||||||||
Brightness | 1000cd/㎡ | ||||||||||
Contrast | 1000:1 | ||||||||||
Brightness Adjustment | Auto and Manual | ||||||||||
Power Consumption | Max Power:<610W | ||||||||||
Average power: <240W | |||||||||||
Module Weight | 0.2kg | ||||||||||
Color Temperature | 9500K—11500K | ||||||||||
Horizontal Viewing Angle | 140º | ||||||||||
Vertical Viewing Angle | 140º | ||||||||||
Signal Processing | 10 or 14bit | ||||||||||
Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
Frame Frequency | 65 Hz | ||||||||||
Refresh Rate | >1920Hz | ||||||||||
Control Mode | Synchronous/Asynchronous | ||||||||||
The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
MTBF | >50000 hours | ||||||||||
Life Span | 100,000 Hours | ||||||||||
Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
Storage : -40 - 85 ℃ | |||||||||||
Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
Power Supply | AC 110–220V | ||||||||||
Protection | dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) |
Customer Service
1) Guarantee Time: Within one year after delivery form factory
2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )
3) Maintenance Mode :
By returned maintenance , through express or by other way
4) Response time for maintenance :Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.
Upgrade Service :
Unschedule,we will upgrade our system of products without extra formal; we'll do our best to help users with upgrading ; the following conditions are excluded by this warranty : Without approved documents;Series code on products having been torn or changed ;Damage caused by lighting strike or electrical problems;Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents. Users or third party refit or repaired by themselves without VEGOO's permission ;Water intrusion or corrosion caused by improper keeping or operating ;Over period of free maintenance .
