P7.62 Indoor Full Color LED Display LED Screen Billboard 1R1G1B / SMD3528 White Lamp
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/ |
| Model Number: | VG-FD 3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Sq.m |
|---|---|
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 15 working days |
| Supply Ability: | 3000 Sq.m / month |
|
Detail Information |
|||
| Product Name: | P7.62 Indoor Full Color LED Display | Certification: | CE/ROHS/FCC |
|---|---|---|---|
| Pixel Pitch: | 7.62mm | Density: | 17,777 Pixel/m2 |
| Moduel Size(L×W)mm: | 244mm×244mm | Contrast: | 1000:1 |
| High Light: | full color led display board,indoor advertising led display |
||
Product Description
1R1G1B/SMD3528 White lamp P7.62 Indoor LED Screen Billboard
Indoor LED Screen Billboard Main Features:
1. Various choices with tight pitch for indoor:P3. P4 p5 p6 P7.62 P10 with brightness from 1500-3500nits to match different application requirement
2. Fanless design:Professional fanless design to make sure the noise less than 25db
3.High refresh rate: 1000:1 contrast ratio ensure the image color more vivid
4.Wide view angle:With 140º view angle ,bring a wonderful image ;
P7.62 Indoor Full color LED Display Specification:
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 7.62mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD3528 White lamp | ||||||||||
| 3 | Density | 17,777 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 244mm×244mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 732mm×732mm×90mm | ||||||||||
| 6 | Module Resolution | 32×32 | ||||||||||
| 7 | Cabinet Resolution | 96×96 | ||||||||||
| 8 | Driving Method | 1/8 Scan | ||||||||||
| 9 | Driving IC | MBI5124 | ||||||||||
| 10 | Brightness | 1200cd/㎡ | ||||||||||
| 11 | Contrast | 1000:1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜650W | ||||||||||
| 14 | Average power: ＜300W | |||||||||||
| 15 | Module Weight | 0.45kg | ||||||||||
| 16 | Color Temperature | 9500K—11500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 10 or 14bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >1920Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 110-220V | ||||||||||
| 36 | Protection | dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
Applications:
Stage Background
Airport Station
Television Relay
Plaza
Square
Expressway
Entertainment
Commercial center
Our services:
1.Could provide LED display project support and do investigation in local places since our customers start the LED display project budget.
2.Customized LED screen software and hardware products will be provided base on customers’ requirements.
3.Provide LED screen technical training (factory or on-site) for different customers.
4.Drawings like steel structure drawing, connection drawing, etc. can be provided after the order.
5.Timely online services are provided whenever there is software operational problems and we’ll solve problems as soon as possible in working with our customers.
