High Brightness Seamless Indoor Full Color LED Display Screen P5 Led Video Wall
Product Details:
Place of Origin: | China |
Brand Name: | Vegoo |
Certification: | CE/ROHS/FCC/ |
Model Number: | VG-FD 3 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Sq.m |
---|---|
Packaging Details: | Plywood case / Flight case / Carton box |
Delivery Time: | 15 working days |
Supply Ability: | 3000 Sq.m / month |
Detail Information |
|||
Product Name: | P5 Indoor Full Color LED Display | Pixel Pitch: | 5mm |
---|---|---|---|
Pixel Configuration: | 1R1G1B/SMD2121 Black Lamp | Density: | 40,000 Pixel/m2 |
Moduel Size(L×W)mm: | 320mm×160mm | Contrast: | 1000:1 |
High Light: | indoor advertising led display,indoor full color led display screen |
Product Description
High brightness seamless SMD2121 1R1G1B P5 Indoor Full color LED Display
Quick Detail:
Indoor Full Color LED Display Features:
1. Relatively low cost;
2. Stable capability;
3. Low energy consumption;
4. Good after-sale
Description:
P5 seamless indoor led screens
1) Relatively low cost
2) Stable capability
3) High brightness
4) Satisfactory after-sales
P5 Indoor Full color LED Display Specification:
Product Name | Specification | ||||||||||
Pixel Pitch | 5mm | ||||||||||
Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
Density | 40,000 pixel/m2 | ||||||||||
Moduel Size(L×W)mm | 320mm×160mm | ||||||||||
Cabinet Size(L×W×H)mm | 640mm×640mm×90mm | ||||||||||
Module Resolution | 64×32 | ||||||||||
Cabinet Resolution | 128×128 | ||||||||||
Driving Method | 1/16 Scan | ||||||||||
Driving IC | MBI5124 | ||||||||||
Brightness | 600CD/㎡ | ||||||||||
Contrast | 1000:1 | ||||||||||
Brightness Adjustment | Auto and Manual | ||||||||||
Power Consumption | Max Power:<500W | ||||||||||
Average power: <200W | |||||||||||
Module Weight | 0.45kg | ||||||||||
Color Temperature | 9500K—11500K | ||||||||||
Horizontal Viewing Angle | 140º | ||||||||||
Vertical Viewing Angle | 140º | ||||||||||
Signal Processing | 10 or 14bit | ||||||||||
Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
Frame Frequency | 65 Hz | ||||||||||
Refresh Rate | >1920Hz | ||||||||||
Control Mode | Synchronous/Asynchronous | ||||||||||
The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
MTBF | >50000 hours | ||||||||||
Life Span | 100,000 Hours | ||||||||||
Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
Storage : -40 - 85 ℃ | |||||||||||
Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
Power Supply | AC 110-220V | ||||||||||
Protection | dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) |
Services Before-sale:
- Set a special telephone line to resolve the confusion from clients and supply free technology services by telephone.
- Consider the demands of clients carefully , study the situation of the installation condition , Team up the related staff and workers promptly , give clients design program details to help them choose the products which they wanted as soon as possible
Service In - sales :
- Try the best to meet the reasonable demands by clients Provisional changed .
- Keep close touch with the clients during the period if installation .
- Cooperate friendly with the clients, satisfy the clients with the best quality of led display .
Service After-sale:
- Normal products have one year guarantee, and whole life maintenance, free charges . we just charge materials cost only if products out off guarantee.
- You can down load and upgrade the related operating software of Led display freely from our company website , so as to resolve the problems when you use our led display .
- Check the quality of appliance , do maintenance job and ask good suggestions form clients on a regular time schedule .
Customer Service
1) Guarantee Time: Within one year after delivery form factory
2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )
3) Maintenance Mode :
By returned maintenance , through express or by other way
4) Response time for maintenance :
- Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;
- Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;
- On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.
Upgrade Service :
Unschedule, we will upgrade our system of products without extra formal; we’ll do our best to help users with upgrading ; the following conditions are excluded by this warranty :
- Without approved documents;
- Series code on products having been torn or changed ;
- Damage caused by lighting strike or electrical problems;
- Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.
- Users or third party refit or repaired by themselves without VEGOO’s permission ;
- Water intrusion or corrosion caused by improper keeping or operating ;
- Over period of free maintenance .
