P5 SMD2121 Full Color Led Sign Commercial Advertising LED Display

China P5 SMD2121 Full Color Led Sign Commercial Advertising LED Display supplier
P5 SMD2121 Full Color Led Sign Commercial Advertising LED Display supplier P5 SMD2121 Full Color Led Sign Commercial Advertising LED Display supplier

Large Image :  P5 SMD2121 Full Color Led Sign Commercial Advertising LED Display

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-FD 3

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sq.m
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 15 working days
Supply Ability: 3000 Sq.m / month
Detailed Product Description
Product Name: P5 Indoor Full Color LED Display Certification: CE/ROHS/FCC
Pixel Pitch: 5mm Pixel Configuration: 1R1G1B/SMD2121 Black Lamp
Brightness: 600CD/㎡ Contrast: 1000:1
High Light:

full color led display board

,

indoor full color led display screen



Commercial Advertising P5 Indoor Full color LED Display SMD2121 lamp





Quick Detail:



Special design
SMD2121 lamp.
it is very easy to install.
Competitive price and trustable quality with two years warranty





Description:



1), LED video Curtain display with CE , ROHS,FCC.

2), High brightness and support brightness automatically adjustment,Mainly used stage show.

3), Long lifespan, can reach more than 100,000 Hours;

4), Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED curtain display system;

5), Rich LED curtain display engineering experience both in domestic and international market.





P5 Indoor Full color LED Display Specification:



Product Name Specification
Pixel Pitch 5mm
Pixel Configuration 1R1G1B/SMD2121 Black lamp
Density 40,000 pixel/m2
Moduel Size(L×W)mm 320mm×160mm
Cabinet Size(L×W×H)mm 640mm×640mm×90mm
Module Resolution 64×32
Cabinet Resolution 128×128
Driving Method 1/16 Scan
Driving IC MBI5124
Brightness 600CD/㎡
Contrast 1000:1
Brightness Adjustment Auto and Manual
Power Consumption Max Power:<500W
Average power: <200W
Module Weight 0.45kg
Color Temperature 9500K—11500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 10 or 14bit
Grey Processing 1024×1024×1024
16834×16834×16834
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >1920Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 110-220V
Protection dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)





Quality Management

  • Implement 5 s site management, general SPC statistical process control methods
  • Through the ISO9001, CE, ROHS, FCC certification
  • Perfect quality, IQC, IPQC, OQC, LQC, QA engineering, QE engineering and supplier management





Upgrade Service :



Unschedule, we will upgrade our system of products without extra formal; we’ll do our best to help users with upgrading ; the following conditions are excluded by this warranty :

  • Without approved documents;
  • Series code on products having been torn or changed ;
  • Damage caused by lighting strike or electrical problems;
  • Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.
  • Users or third party refit or repaired by themselves without VEGOO’s permission ;
  • Water intrusion or corrosion caused by improper keeping or operating ;
  • Over period of free maintenance .
