Full Color Small Pitch P1.25 160×120 LED TV Displays

Large Image : Full Color Small Pitch P1.25 160×120 LED TV Displays

Product Details:

Place of Origin:	China
Brand Name:	Vegoo
Certification:	CE
Model Number:	VG-dh-3

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm
Price:	Negotiable
Packaging Details:	Plywood case / Flight case / Carton box
Delivery Time:	10-20 days
Payment Terms:	T/T
Supply Ability:	8000sqm/month

Contact Now

Detailed Product Description

Pixel Pitch:

1.25 Mm

Density:

640,000 Pixel/m2

Cabinet Weight:

4.2kg

Driving Method:

1/30 Scan

High Light:

160×120 led tv panel

P1.25 led tv screen

Product Description

1) Super small pixel pitch, show ultra hd image and video for advertising and rental market;

2) High precision and best quality LED and Drivers, high refresh rate, high grey level;

3) Small panel, one panel one receiving card, easy to operate and move;

4) Die Cast Aluminum Cabinet, durable and won't deform;

5) Support Different Input and output signals.

P1.25 Indoor Full color LED Display Specification

NO:

Product Name

Specification

Pixel Pitch

1.25 mm

Pixel Configuration

1R1G1B/SMD1010 Black lamp

Density

640,000 pixel/m2

Moduel Size(L×W)mm

200mm×150mm×8mm

Cabinet Size(L×W×H)mm

400mm×300mm×60mm

Module Resolution

160×120

Cabinet Resolution

320×240

Driving Method

1/30 Scan

Driving IC

MBI5153/ICN 2153/FM6353

Brightness

600-800CD/㎡

Contrast

4000 :1

Brightness Adjustment

Auto and Manual

Power Consumption

Max Power:＜900W

Average power: ＜100-300W

Cabinet Weight

4.2kg

Color Temperature

2000K—9500K

Horizontal Viewing Angle

140º

Vertical Viewing Angle

140º

Signal Processing

16bit

Grey Processing

1024×1024×1024
16834×16834×16834

Control Distance

cable100m,Multimode500m,Single mode 2km

Frame Frequency

65 Hz

Refresh Rate

>3840Hz

Control Mode

Synchronous/Asynchronous

The Opposite Calibration Curve

With Eight Optional Gamma Calibration Curve

Users can choose the recommended curve or adjust it based on actual situation

MTBF

>50000 hours

Life Span

100,000 Hours

Operating Temperature

Working : -10 - 60 ℃

Storage : -40 - 85 ℃

Environment Temperature

-10℃ to 60℃; humidity Rh10% to 90%

Remote Control

Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)

Self-checking Technique

Self-inspection, communication test, power test, temperature monitoring (Be customized)

Operating System Platform

WindowsXP/7/8/10

Power Supply

AC110-240V / 5V60Hz

Protection Level

IP 45
