High Resolution Full Color 10mm SMD LED Module Led Advertising Screen

China High Resolution Full Color 10mm SMD LED Module Led Advertising Screen supplier
High Resolution Full Color 10mm SMD LED Module Led Advertising Screen supplier High Resolution Full Color 10mm SMD LED Module Led Advertising Screen supplier

Large Image :  High Resolution Full Color 10mm SMD LED Module Led Advertising Screen

Product Details:

Place of Origin: China
Brand Name: Vgeoo
Certification: Ce/ROHS/FCC/
Model Number: VG-RD P10

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sq.m
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 7 days
Detailed Product Description
Product Name: P10 Outdoor Full Color LED Display Density: 10,000 Pixel/m2
Cabinet Size(L×W×H)mm: 960mm×960mm×130mm Module Resolution: 32×16
Driving IC: MBI5124 Contrast: 1000:1
High Light:

led screen module

,

led video module



P10 Outdoor Full color LED Display 960mm×960mm×130mm





Description:



1 Rich advertising LED screen engineering experience both in domestic and oversea market.

2. product stability through strict quality control system.

3. Price Advantage:Best competitive price for indoor smd led display.

4. Performance Advantage:Best quality,high consistency,high refresh rate,best brightness,large viewing angle.
5. Quality Advantage:From material to finished product,from design to produce,we control all steps,include the guarantee of the quality and reliability.
6. Service Advantage:with professional service team for 24 hours service,better service at same situation.





Remote Control

Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)





P10 Outdoor Full color LED Display Specification



NO: Product Name Specification
1 Pixel Pitch 10mm
2 Pixel Configuration 1R1G1B/DIP 346
3 Density 10,000 pixel/m2
4 Moduel Size(L×W)mm 320mm×160mm or 160mm×160mm
5 Cabinet Size(L×W×H)mm 960mm×960mm×130mm
6 Module Resolution 32×16
7 Cabinet Resolution 96×96
8 Driving Method 1/ 4 Scan
9 Driving IC MBI5124
10 Brightness 7500cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power: <850W
14 Average power: <340W
15 Module Weight 0.5kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)







Customer Service





1) Guarantee Time: Within one year after delivery form factory

2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )

3) Maintenance Mode :

By returned maintenance , through express or by other way

4) Response time for maintenance :



1. Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;



2. Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;



3. On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.
