High Reliability P3.91 Stage Led Display With Auto / Manual Brightness Adjustment

China High Reliability P3.91 Stage Led Display With Auto / Manual Brightness Adjustment supplier
High Reliability P3.91 Stage Led Display With Auto / Manual Brightness Adjustment supplier High Reliability P3.91 Stage Led Display With Auto / Manual Brightness Adjustment supplier

Large Image :  High Reliability P3.91 Stage Led Display With Auto / Manual Brightness Adjustment

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-FD 3.91

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sq.m
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 15 working days
Supply Ability: 3000 Sq.m / month
Detailed Product Description
Product Name: Stage LED Screens Pixel Pitch: 3.91mm
Pixel Configuration: 1R1G1B/SMD2121 Black Lamp Density: 65,536 Pixel/m2
Moduel Size(L×W)mm: 250mm×250mm Cabinet Size(L×W×H)mm: 500mm×500mm×90mm
Module Resolution: 64×64 Cabinet Resolution: 128×128
Driving Method: 1/16 Scan
High Light:

stage led display

,

stage background led screen


High reliability Stage LED Screens Auto and Manual Brightness Adjustment


Description:


1) High reliability: using distributed scanning technology and module design technology that make higher reliability and stability.



2) Favorable effect: using dot to dot calibration technology makes the image clearer and the layering stronger.



3) Steady and reliable system, with strong anti-interference ability and long service life that can continually work for over 24 hours,and it’s easy to operate the system.



4) Convenient installation and maintenance of display modules.




P3.91 Indoor Full color LED Display Specification



NO: Product Name Specification
1 Pixel Pitch 3.91mm
2 Pixel Configuration 1R1G1B/SMD2121 Black lamp
3 Density 65,536 pixel/m2
4 Moduel Size(L×W)mm 250mm×250mm
5 Cabinet Size(L×W×H)mm 500mm×500mm×90mm
6 Module Resolution 64×64
7 Cabinet Resolution 128×128
8 Driving Method 1/16 Scan
9 Driving IC MBI5124 or ICN 2038S
10 Brightness 1000cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:<600W
14 Average power: <200W
15 Module Weight 0.52kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 160º
18 Vertical Viewing Angle 120º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)





Services Before-sale:





Set a special telephone line to resolve the confusion from clients and supply free technology services by telephone.



Consider the demands of clients carefully , study the situation of the installation condition , Team up the related staff and workers promptly , give clients design program details to help them choose the products which they wanted as soon as possible



Service In - sales :





Try the best to meet the reasonable demands by clients Provisional changed .

Keep close touch with the clients during the period if installation .

Cooperate friendly with the clients, satisfy the clients with the best quality of led display .



Service After-sale:





Normal products have one year guarantee, and whole life maintenance, free charges . we just charge materials cost only if products out off guarantee.

You can down load and upgrade the related operating software of Led display freely from our company website , so as to resolve the problems when you use our led display .



Check the quality of appliance , do maintenance job and ask good suggestions form clients on a regular time schedule .
