High Resolution Transparent Video Glass Screen , P20 DIP 346 Outdoor Led Panel

China High Resolution Transparent Video Glass Screen , P20 DIP 346 Outdoor Led Panel supplier
High Resolution Transparent Video Glass Screen , P20 DIP 346 Outdoor Led Panel supplier High Resolution Transparent Video Glass Screen , P20 DIP 346 Outdoor Led Panel supplier

Large Image :  High Resolution Transparent Video Glass Screen , P20 DIP 346 Outdoor Led Panel

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE/ROHS/FCC/
Model Number: VG-SD P20

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sq.m
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 20-25 working days
Supply Ability: 3000 Sq.m/ Month
Detailed Product Description
Product Name: Outdoor Full Color LED Display Pixel Pitch: 20mm
Pixel Configuration: 1R1G1B/DIP 346 Density: 2,500 Pixel/m2
Cabinet Size(L×W×H)mm: 960mm×320mm×90mm Module Resolution: 48×0.85
Cabinet Resolution: 48×16 Brightness: 5500CD/㎡
High Light:

transparent led panel

,

transparent led video wall

P20 DIP 346 Outdoor Full color LED Display Transparent LED Screen





Description:





* High Degree of Visibility
80% transparent see-through, so it is convenient for people inside and outside to look-through. The integrated LED lamps are very tiny and almost invisible from outside of the building.


* Compact Design and Light Weight
almost suitable for any glass wall building.The weight is only 18kg/sqm and minimizes the load to the glass wall.


* Ease of the Installation and Maintenance
No need to change any building structure. The modules can be stuck to the back of the glass wall by the special glue which presented by us. It needs only 10 second to install one module. Should any maintenance occurs, it only requires to do it at the indoor.


* Saving Money in Decoration for the Architecture
Since the LED glass wall makes the vivid decoration and advertising, it saves other lights to lighting up the building.


* Wide Application
The Glass Wall LED Screen can be applied wherever the glass wall existed such as commercial building,landmark,architecture, art center,shopping mall, super market, shain stores etc.





P20 DIP 346 Outdoor Full color LED Display Specification





NO: Product Name Specification
1 Pixel Pitch 20mm
2 Pixel Configuration 1R1G1B/DIP 346
3 Density 2,500 pixel/m2
4 Moduel Size(L×W)mm 960mm×17mm
5 Cabinet Size(L×W×H)mm 960mm×320mm×90mm
6 Module Resolution 48×0.85
7 Cabinet Resolution 48×16
8 Driving Method 1 Scan
9 Driving IC MBI5124
10 Brightness 5500CD/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power: <600W
14 Average power: <450W
15 Cabinet Weight 18kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)





Services Before-sale:



Set a special telephone line to resolve the confusion from clients and supply free technology services by telephone.



Consider the demands of clients carefully , study the situation of the installation condition , Team up the related staff and workers promptly , give clients design program details to help them choose the products which they wanted as soon as possible



Service In - sales :



Try the best to meet the reasonable demands by clients Provisional changed .

Keep close touch with the clients during the period if installation .

Cooperate friendly with the clients, satisfy the clients with the best quality of led display .



Service After-sale:



Normal products have one year guarantee, and whole life maintenance, free charges . we just charge materials cost only if products out off guarantee.

You can down load and upgrade the related operating software of Led display freely from our company website , so as to resolve the problems when you use our led display .



Check the quality of appliance , do maintenance job and ask good suggestions form clients on a regular time schedule .
