P4 Indoor Full Color LED Display

China P4 Indoor Full Color LED Display supplier
P4 Indoor Full Color LED Display supplier P4 Indoor Full Color LED Display supplier

Large Image :  P4 Indoor Full Color LED Display

Product Details:

Place of Origin: CHINA
Brand Name: VEGOO
Certification: CE ROHS FCC CCC
Model Number: VG-SUN88866

Payment & Shipping Terms:

Minimum Order Quantity: 1 SQM
Price: negotiate
Packaging Details: flight case,plywood case,carton
Delivery Time: 15-30 working days
Payment Terms: T/T
Supply Ability: 3000 sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 4mm Density: 62,500 Pixel/m2
Moduel Size: 256mm×128mm Cabinet Size: 512mm×512mm×90mm
Driving Method: 1/16 Scan Contrast: 1000:1
High Light:

P4 indoor rental led display

,

SMD2121 rgb led display

High Brightness P4 Indoor Rental Led Display Panel Video Wall With Flight Plug Utra-Thin





Product features:

  1. Black body LED lamp for high contrast rate;
  2. Stable Good quality: we have stable raw materials suppliers such as The lamp; the IC; the power supply; the control system etc. Every step, we have strict quality control;
  3. High screen flatness local inaccuracy and seamless connection;
  4. P4 HD full color LED video wall for rental;
  5. Thin Die-cast aluminum design high precision thickness;
  6. Can be hanging, good for rental use;





P4 Indoor Full color LED Display Specification



Product Name Specification
Pixel Pitch 4mm
Pixel Configuration 1R1G1B/SMD2121 Black lamp
Density 62,500 pixel/m2
Moduel Size(L×W)mm 256mm×128mm
Cabinet Size(L×W×H)mm 512mm×512mm×90mm
Module Resolution 64×32
Cabinet Resolution 128×128
Driving Method 1/16 Scan
Driving IC MBI5124 or FM6124
Brightness 1000cd/㎡
Contrast 1000:01:00
Brightness Adjustment Auto and Manual
Power Consumption Max Power:<410W
Average power: <200W
Cabinet Weight 6.5kg
Color Temperature 2000K—9500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 16bit
Grey Processing 1024×1024×1024
16834×16834×16834
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >1920Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 110–220V/5V60Hz
Protection Level IP 45



P4 Indoor Full Color LED Display 0



Our service:

  1. We provide 1-3 years of product quality assurance;
  2. Our products are full time of the aging test before the shipped , and quality control to ensure that our product's quality;
  3. Reply in a timely manner, and one-time solution to customer problems, to ensure that customers install and use the product ;
  4. We can provide our customers with professional steel drawings to install the LED display .

FQA:

Question 1: what is LED display?
Answer 1: LED full color led display is composed of many LEDs. One pixel is made up of three colors of LEDs, colors of LED can be divided into R.G.B.led display screen can show letters,pictures.video, images and so on;
Question 2: Indoor vs outdoor?
Answer 2: Indoor signs are bright enough to be seen inside a building under commercial lighting, but not bright enough to be seen in direct sunlight. Outdoor signs can be seen in full-on, mid-day sunlight, and are weatherproof to withstand the harsh environmental conditions;
Question 3: What about the lead time?
Answer 3:Order less than 40 square meter led time take 25 working days;
Question 4:Where is it used for?

Answer 4:Outdoor & rental use. Widely used for backdrop of staging event, rental business, live show, concert, etc.
